Processor
| RK3399, up to 64 bit high performance CPU, 2.0GHz; dual-core Cortex-A72 + quad-core Cortx-A53 64-bit CPU+ build in MCU Cortex-M0
|
GPU
| Quad-core ARM Mali-T860MP4 high performance GPU
|
Memory
| 2GBytes DDR3 (up to 4G)
|
Storage
| 16G Bytes Nand Flash/EMMC
|
ROM
| 32KB EEPROM
|
Decoding Resolution
| 3840*2160
|
Operation System
| Android 7.1
|
Display
| LVDS, HDMI (4K HD Output)
|
Video Format
| Wmv, avi, flv, rm, rmvb, mpeg, ts, mp4
|
Picture Format
| BMP, JPEG, PNG, GIF
|
USB Connector
| type C*1, USB3.0*1, USB2.0*1
|
Mipi Camera
| 30pin FPC *1, support 1300w camera
|
Parallel Connector
| RC232*2, 485*1, TTL*1, DEBUG*1
|
External GPS
| Optional
|
Network
| ETH 10M/100M/1000M, WIFI/ BT4.1
|
TF Card
| Support
|
LVDS out
| Single/double way *1, can drive 50/60Hz LCD direclty
|
eDP out
| Drive multiple resolution LCD directly
|
HDMI out
| Support 1080P@60Hz,4kx2k@60Hz
|
HDMI in
| HDMI input,24pin FPC customized connector
|
Audio out
| R/L, build in double 4R/20W, 8R/10W
|
Power
| DC 12V
|
Working Temperature
| -20ºC~60ºC
|
Storage Temperature
| -20ºC~60ºC
|
System Upgrade
| USB Local Upgrade
|
Play Mode
| Support cycle playing, time playing and emergent playing
|
