CNC Slant Bed Lathe Stc5052D with Rotary Chunk Dual Tool Holders Cutting Machine Milling Machine Lathe
| US$18,500.00-20,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
STC5052D
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools
Movement Method
Point to Point Control
Control Method
Open-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.01~0.02(mm)
Performance Classification
High-End CNC Machine Tools
Condition
New
CNC System
GSK
Chuck
Rotary Chuck 265/400mm
Optional CNC System
Fanuc, Mitsubishi M80, Siemens, Knd, Nanjing Kt
Optional Chuck
Hydraulic Chuck
Transport Package
Seaworthy Packing
Specification
2680*1695*1800 mm
Trademark
JT
Origin
China
HS Code
8458110000
Production Capacity
1500 Sets/Year
Product Description
The STC5052D is a versatile and high-performance CNC machine, equipped with a rotary chuck and dual tool holders for enhanced machining capabilities. It offers flexibility with interchangeable control systems, allowing users to choose from GSK, Fanuc, Siemens, Mitsubishi, and other leading CNC controllers to suit their specific operational needs. Designed for precision and efficiency, the STC5052D is ideal for complex machining tasks, ensuring high productivity and reduced setup times in a wide range of applications.
Product Parameters
| ITEM | UNIT | STC5052D | |
| Maximum rotation diameter on the bed | mm | φ500 | |
| Maximum turning diameter on the slide | mm | φ300 | |
| Spindle | Spindle end type | A2-8 | |
| Spindle through hole diameter | mm | φ82 | |
| Maximum spindle speed | r/min | 1600 | |
| Diameter of the through hole of the drawn tube | mm | φ68 | |
| Chuck | 400mm rotary chuck | ||
| Main motor | main motor power | kw | 15 |
| Two Axis | X/Z axis fast moving speed | m/min | 15/20 |
| X-axis travel | mm | 380 | |
| Z-axis travel | mm | 550 | |
| Tool holder | Tool holder form | Four workstations | |
| Knife Square | mm | 25*25 | |
| Tool bar diameter | mm | φ32 | |
| Accuracy | Precision | It6 | |
| Roundness of workpiece | mm | 0.005/φ70 | |
| Processing surface roughness | um | Ra1.6 | |
| X/Z repeat positioning accuracy | mm | 0.01/0.011 | |
| General Rules | Machine net weight | kg | 2800 |
| Machine tool dimensions | mm | 2680*1695*1800 | |
