Paper Mills Vertical Hydraulic Drum Pulper for Pulp Stock Preparation Line

Product Description

Product Description
Middle consistency hydra pulper is mainly used to break various pulp boards, broken paper, and various waste papers. It has the characteristics of strong dispersing ability, wide application range, simple structure, convenient operation and maintenance, etc. It is the ideal equipment for waste paper pulping at present. This series of hydraulic pulpers is suitable for both intermittent production and continuous production.
High consistency hydraulic pulper is mainly used for rapid pulping under conditions of high consistency and 60-90ºC water in the deinking process. At the same time, ink particles and fiber are separated through chemical action. Almost no size reduction of ink particles and rejects makes subsequent ink removal, screening, and cleaning processes easier and smoother. Pulp with a high degree of whiteness can be made from waste paper using less steam and chemicals with lower power consumption. High consistency hydra pulper has become the core equipment in the waste paper deinking and pulping process.
Detailed Photos
Packaging & Shipping
Product Parameters
Middle consistency hydrapulper:

Model	ZDSM24	ZDSM25	ZDSM26	ZDSM27	ZDSM28	ZDSM29	ZDSM30	ZDSM31	ZDSM32
Nominal Volume (m3)	10	15	20	25	30	40	50	70	90
Consistency (%)	5-8
Capacity (T/D)	40-60	60-90	90-130	120-170	150-200	220-290	300-400	450-600	600-800
Motor Power (kW)	90	132	185	250	250	315	400	630	800

High consistency hydrapulper:

Model	ZDSH5	ZDSH10	ZDSH15	ZDSH20	ZDSH25	ZDSH30	ZDSH35
Nominal Volume (m3)	5	10	15	20	25	30	35
Consistency (%)	10-15
Capacity (T/D)	20-25	40-50	60-70	80-100	130-185	160-225	185-260
Motor Power (kW)	110	220	310	400	450	500	560
