Industrial wool dewatering machine sheep washing production line processing wool machinery

Product Description

Product Description
Industrial wool dewatering machine sheep washing production line processing wool machinery
processing wool machinery brief introduction:
This wool washing machine made of stainless steel,the material is wearable and easy to clean.Opean the door and put the dirty wool into it,add wool cleaner,shut the door,the water will into the machine automatically,select the washing time(usually 40 minutes),the machine will wash the wool very efficiency.
Details:
processing wool machinery main parameter;

Model	JXGX-50	JXGX-100	JXGX-150
Max washing capacity	50kg	100kg	150kg
Drum size (mm)	800*980	960*1420	1060*1650
Power (kw)	1.5	3	4
r/m	36	34	33
Water consumption(kg)	520	820	1000
Steam pressure (Mpa)	0.4-0.6	0.4-0.6	0.4-0.6
Dimensions (mm)	1750*1200*1500	2300*1400*1850	2560*1330*1520
Weight (kg)	900	1750	1850

Wool dewater machine
Details:

Model	JXSS-600	JXSS-800	JXSS-1000
Diameter (mm)	600	800	1000
High of drum(mm)	300	340	380
Speed of drum (r/min)	1000	910	900
Motor power(kw)	3	4	5.5
Capacity (kg)	45	80	130
Weight (kg)	450	850	1300
Dimension (mm)	1250*1250*700	1500*1500*800	1800*1800*900

Wool drying machine(electrical heating or gas heating)
The wool after dewatering,put them into the drying machine,drying about 40 minutes,the wool come out of the machine will be dry wool,can be packed into bags.
Details:

Model	JXWA-50	JXWA-100	JXWA-150
Capacity(kg)	50	100	150
Drum dimension(mm)	1160*1000	1320*1100	1600*1160
Drum speed (mm)	32	30	27
Steam pressure (Mpa)	0.4-0.6	0.4-0.6	0.4-0.6
Power (kw)	3	4.4	7.4
Dimensions (mm	1320*1700*2200	1500*1800*2360	1720*1900*2000

processing wool machinery pictures:
