High-Performance 4 Axis CNC Deep Hole Gun Drilling Machine for Metal

High-Performance 4 Axis CNC Deep Hole Gun Drilling Machine for Metal

US$32,000.00-60,000.00 1 set (MOQ)

Basic Info.

Model NO.
VMD-650
Structure
Vertical Drilling Machine
Layout
Vertical
Controlling Mode
CNC
Number of Shaft
4
Hole Diameter
<50mm
Automatic Grade
Automatic
Precision
High Precision
Certification
CE, ISO 9001
Condition
New
Model
Vmd-650
Inner Diameter of Drilling
1.5-20mm
Max Drilling Depth
220mm
Table Size
700*520mm
X Aixs Travel
600mm
Y Axis Travel
500mm
Z Axis Travel
300mm
Z2 Axis Travel
300mm
Drilling Cutting Speed
1-300mm/Min
Spindle Taper
Bt40
Max Spindle Rotary Speed
10000rpm
Xyz Axis Motor
2.4/3.1/3.9kw
Z2 Axis Motor
3.9kw
Load Weight
500kgs
Machine Diamension
2800*2880*2600mm
Transport Package
Wooden Pallet and Wooden Case
Specification
2800*2880*2600mm
Trademark
JOINT MACHINERY
Origin
China
HS Code
8459210000
Production Capacity
300

Product Description


Drilling stands as the fundamental cornerstone in machining operations, boasting a wide-ranging application field. Traditional drilling equipment like bench drills, milling machines, and radial drills have historically shackled laborers to repetitive tasks, often compromising quality. The constraints of security, efficiency, and processing limits have long affected manufacturers and operators. Enter the era of CNC technology-the revolutionary CNC deep hole drill has transformed this landscape. It emancipates the workforce, overcomes the bottleneck of deep drilling processes, and achieves the exceptional processing quality of traditional machines in drilling, enlarging, and expanding operations. Additionally, it automates chip removal, CNC positioning, and processing-ushering in a new age of precision and efficiency.
3 Axis CNC Deep Hole Drilling Machine 4 Axis Vertical CNC Deep Hole Drilling Machine Multi-Spindle CNC Deep Hole Drilling Machine 6 Axis CNC Deep Hole Drilling Machine

4-Axis Vertical CNC Deep Hole Drilling Machine Introducing a groundbreaking vertical deep hole drill, featuring a specialized short gun drill ideal for small hole processing and tailored for batch injection pinhole operations. This innovation promises high precision, remarkable speed, and user-friendly operation while significantly reducing manpower requirements. Its versatility shines in fields like medical equipment, aerospace, hydraulic oil pumps, automotive spare parts, and beyond.
High-Performance 4 Axis CNC Deep Hole Gun Drilling Machine for Metal
Model Unit VMD-650
Inner diameter of drilling mm 1.5-20
Max drilling depth mm 220
Table size mm 700*520
X/Y/Z axis travel mm 600*500*300
Z2 axis travel mm 300
Drilling cutting speed m/min 1-300
Spindle taper BT40
Max spindle rotary speed rpm 10000
Spindle motor power kw 7.5-11
X/Y/Z axis motor kw 2.4/3.1/3.9
Z2 axis motor kw 3.9
Load weight kgs 500
Machine weight kgs 4500
Machine dimension mm 2800*2880*2600

Shenzhen Joint Machinery Co., Ltd. stands as a distinguished professional manufacturer and exporter of CNC lathe machines, CNC deep hole drilling machines, Swiss-type automatic lathes, milling machines, grinding machines, and more. Our unwavering commitment is to deliver top-tier machines and exceptional service to our global clientele. We focus on rigorous quality control and continuous improvement to ensure our machines surpass the highest industry standards. By integrating cutting-edge technologies from Taiwan and Germany with advanced production equipment and processes, we guarantee superior quality and reliability. Our machines are renowned for their precision, stability, and dependability, adept at handling complex and high-demand machining tasks. With a strong global presence, our products are exported worldwide, earning widespread recognition and popularity. Our market reach extends across Asia, Europe, South America, North America, and more. We pride ourselves on establishing enduring partnerships with customers worldwide, fostering mutual growth and creating substantial business value.
