Full Hydraulic Operation Cheap Price Crawler Excavator Stage III for Sale

Product Description

Product Description
The crawler excavator is a economic type excavator, which matched the KUBOTA engine with III stage emissiob with strong power and low fuel consumption and environment protection.Fitted the famous brand main pump and main valve from chinaAdopted the hydraulic pilot servo controlling system , ensure the machine has high working efficiencyThe professional structural parts and working mechanism, ensure the machine has relibility and durabilityThe machine installed closed cabin with A/C and LCD display and LED lampsThe humanized design , ensure the machine can comfortable operation and convenient maintenance
Product Parameters

emission standard for engine	stage III
Make/ Model	KUBOTA/V2607
rated power	42.4kw/2000rpm
bucket capacity	0.21m3
Machine weight	6000kg
overall dimension(L*W*H)	5940mm*1880mm*2570mm
Max.digging height	5499mm
Max.digging depth	3808mm
Max.digging radius	6128mm
Min.swing radius	2607mm

ENGINE
Emission Standard	Tier 3/ Stage III
Make /Model	KUBOTA/V2607
Power /Rotation speed	42.4kw(58HP)@2000rpm
Number of cylinder	4
TRACK SYSTEM
Maximum Travel speed	2.4/4.3 km/h
Width of track shoe	400mm
Number of track shoe per side	40pcs
Number of upper roller per side	1
Number of bottom roller per side	5
PERFORMANCE PARAMETER
Standard Bucket capacity	0.21m³
Swing speed	11rpm
Maximum Grade ability	35°
Maximum Bucket digging force	48KN
Maximum Arm digging force	35KN
Hydraulic system pressure	28Mpa
Machine weight	5800kg
Fuel tank	87L
Hydraulic oil tank	100L
MACHINE SIZE
Overall dimension (L*W*H)	5940mm*1880mm*2570mm
Height of cabin	2600mm
Track length on ground(Axle base)	1990mm
Track gauge	1480mm
Minimum Ground clearance	353mm
Swing radius at tail	1689mm
WORKING RANGE
Maximum Digging height	5499mm
Maximum Dumping height	3845mm
Maximum Digging depth	3808mm
Maximum Vertical digging depth	2983mm
Maximum Digging radius	6128mm
Minimum swing radius	2607mm
Maximum Lifting height of blade	376mm
Maximum Cutting depth of blade	474mm

Detailed Photos
Confortable seat and hydraulic operational joystick
This crawler excavator equiped with Original Kubota Engine,Eaton swing motor and traveling motor which provide stable and strong power to the machine
JH20 also equiped with rubber track,0.21m3 bucket,swing boom and extend hydraulic hose system for extra attachments.


veling motor which provide stable and strong power to the machine
JH20 also Various attachments are available for different working purpose
