CNC Horizontal Boring Milling Drilling Machine Tools Machine CNC Machining Tools Cutting
Basic Info.
Model NO.
HMC63
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools
Movement Method
Contour Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.01~0.02(mm)
Performance Classification
Economical CNC Machine Tools
Certification
CE
Condition
New
Spindle Taper
Bt30
Spindle Motor
5.5kw
System
Syntec/Mitsubishi/Fanuc/Siemens
Name
CNC Horizoncal Milling Machine
X/Y/Z Speed
48/48/48 M/Min
Tool Alignment
Auto Tool Checking
Working Table
424*396
Precision
+-0.005/300mm
Repeat Precision
+-0.003mm
Power
5.5kw 380V 3 Phase
Spindle Speed
20000 Rpm
Max Working Speed
10000mm/ Min
Applicable Industries
Machinery Repair Shops, Manufacturing Plant, Mold
Type
3 Axis CNC Machine
Transport Package
Sea Worthy Plywood Case
Specification
2700*2900*2600
Trademark
WT
Origin
Dongguan City China Prc
HS Code
8459619000
Production Capacity
2000PCS/Year
Product Description
High-speed and high-precision hot-selling metal cutting HMC30 CNC horizontal machining center CNC machining centerProduct Description
Standard X/Y/Z three-axis heavy-duty roller linear guide, equipped with 20000/12000RPM direct spindle, can realize high-speed, high-precision, high-gloss machining. With high-precision CNC turntable, it can realize one-time clamping, multi-process, multi-face and one-time machining.
Product Paramenters
| Item | Unit | HMC30 | HMC50 | HMC80 |
| Workbench area (LxW) | mm | 424x396 | 585x390 | 800x600 |
| Optional rotary table size | mm | Φ210 | Φ320 | Φ320 |
| Allowable load | kg | |||
| X/Y/Z axis travel | mm | 500/450/450 | 800/600/600 | 1100/600/600 |
| Spindle end face to table center | mm | 100-550 | 120-750 | 180-780 |
| Spindle center to table top | mm | 0-450 | 0-600 | 140-710 |
| Spindle taper hole | No. | BT30 | BT40 | BT40 |
| Spindle maximum speed | r/min | 20000 | 12000 | 12000 |
| Spindle motor maximum power | kw | 5.5 | 11 | 11 |
| Feed | X/Y/Z three-axis heavy-duty roller linear way | |||
| X/Y/Z axis rapid traverse speed | m/min | 48/48/48 | 48/36/48 | 36/36/36 |
| Maximum chip speed | mm/min | 10000 | 10000 | 10000 |
| Number of tools | T | 24 | 24 | 24 |
| Positioning accuracy | mm | ±0.005/300 | ±0.005/300 | ±0.005/300 |
| Repeatability | mm | ±0.003 | ±0.003 | ±0.003 |
| Machine weight | kg | 4500 | 6000 | 7500 |
