Joborn Multi-Blade Giant Disc Bridge Saw Stone Block Cutting Machine Automatic Slab Cutting Line Machine for Natural Stone and Artificial Stone

Product Description

JOBORN Multi-Blade Giant Disc Bridge Saw Stone Block Cutting Machine Automatic Slab Cutting Line Machine For Natural Stone and Artificial Stone
JOBORN SQC2200/2500/2800-4D Plus+ Block Cutting Machine. This series machine adopts microcomputer control system and human-machine interface, uses inverter to control left-right feeding, adjusts the speed according to the stone material. It uses hydraulic lifting system , combination of chrome-plated guide pin and wear guide bush, with small gap , wearable, beautiful structure , and guide sleeve with multi-layer seals , with waterproof , dust-proof , anti-spill , improving the service life, main motor uses brand energy-efficient motor, reduces the later using cost; forward-backward automatic slicing uses high-precision screw nut driving, main spare parts adopt imported good-quality materials; The block can be placed in the ground directly to save worktable and its maintenance costs; thus the whole machine is featured as high cutting efficiency, high slicing precision, and flatness of plate after cutting, high stability, easy-operating to suit specially cutting granite and marble block with high value and big size.
Features: 1.Taiwan famous hydraulic system.The hydraulic components from Taiwan first-line brand,react more quickly,works more stable.
2.Domestic premium brand main motor with high efficiency and more energy saving,make the cutting more powerful,and saving electricity more.
3.Germany Siemens inverter, feeding more stable; imported or domestic famous brand electrical components, with lower failure rate, help you to worry less and save more labor.
4.Side-beam rails use slide V-rail, contacting area is large, not easy to shake when cutting, ensure the plate/slabs are flatness after cutting; meanwhile,the forward and backward slicing take high precision screw-nut transmission, have automatic slicing fuction.
5.It uses hydraulic lifting system, combination of chrome-plated guide pin and wear guide bush, with small gap, wearable, beautiful structure, and guide sleeve with multi-layer seals, with waterproof, dust-proof, anti-spill, improving the service life.
6.Rotating working platform (Optional)
Processing Display:
Product Parameters

SQC2200/2500/2800-4D Plus+(26 Blades) Block Cutting Machine (Plus+)
Appellation	Unit	SQC2200-4D Plus+	SQC2500-4D Plus+	SQC2800-4D Plus+
Max.Diameter of saw blade	mm	Φ2200	Φ2500	Φ2800
Left right stroke	mm	5800	5500	5200
Front rear stroke	mm	4000
Max.lifting stroke	mm	1350
Power of main motor	kW	90
Total power	kW	105
Water consumption	m³/h	18
Dimension(LxWxH)	mm	10000x6000x3700(base to peak)
Weight	kg	20000

Processing Spot:
Hot Sales

Company Profile
We JOBORN Machinery, specialized in Producing Stone Factory Machines, such as Bridge Saw Stone Cutting Machine / Stone Slab Cutting Machine, Tiltable Bridge Cutting Machine, CNC 5-Axis Bridge Cutting Machine, Middle Block Cutting Machine, Giant Disc Bridge Saw Machine, Multi-blade Stone Block Cutting Machine, Manual Stone Cutting Machine, Automatic Stone Polishing Machine/Slab Polishing Line Machine, Manual Polishing Machine, Automatic Stone Calibrating Machine, Automatic Stone Profiling Machine, CNC Bridge Profiling Machine, Automatic Litchi-surface Grinding Machine / Bush Hammering Machine, as well as Stone Machine Accessories.
As one of the "Top Ten Stone Machine Manufacturers in China", our machines are all produced with High quality standard, easy to use, operation stable, durable, with long life cycle and low overall use cost. They are perfect for process Natural Granite and Marble; also good for used to process other Natural Stone as per customer's need, including Sandstone, Limestone, Slate, Basalt, Travertine, Onyx, etc.; as well as process Artificial stones.
Customer Application
FAQ
Q: Are you manufacturer ?
A: Yes, we are professional and top stone machine manufacturer more than 30 years in China. Also we have many authorized agents all over the world to take care of machine's after sell service. Q: Can I get a machine according to my own requirements? A: Sure. Welcome OEM and ODM orders. Q: This is the first time I use this kind of machine, is it easy operate? A: There are guide video that show how to use machine and English instruction manual sent to you with machine. If there is still have any question, we will provide free professional online guide for you until you could use machine well. Q: What's your MOQ and delivery? A: Our MOQ is 1 set. We could send machine to your country port or to door directly, please tell us your port name or address. We'll offer the most competitive price and freight to you. Q: How is your after sales service? A: We offer machine lifelong's free online guide service. And many countries we have local dealer to do machine's installation and maintenance. Q: If my machine is broken. Can you repair it for me? A: Yes, many machines of us have remote troubleshooting function, we can solve by remote control and video guide. Re. common problems, we have professional guideline to show how to replace the parts, and for the countries which our agents cover, they will repair for you as well.
