Round Column Vertical Drilling Machine (Z5032A)
Basic Info.
Model NO.
Z5032A
Structure
Vertical Drilling Machine
Layout
Vertical
Controlling Mode
Artificial
Number of Shaft
1
Hole Diameter
<50mm
Automatic Grade
Manual
Precision
High Precision
Certification
CE, ISO 9001
Condition
New
32mm Drilling Capacity
Spindle Taper Mt4
Model
Z5032A
Color
White and Blue
Size
103 61 209
Weight
550
Drilling Capacity
32 mm
Transport Package
WOOD CASE
Specification
CE, ISO9001
Trademark
UNI-TECH
Origin
CHINA
HS Code
84592900
Production Capacity
100SETS/MONTH
Product Description
Vertical Drilling Machine1. New-designed, compact construction
2. CE, UL approved main electrical components
3. Auto feed and tapping controlled by electromagnetic clutch, realize auto feed and tapping by putting any button on the feed handle
4. Gear driven system, 12 speed steps
5. Spindle box and Worktable can be rotated ± 180° And tited± 45°
6. Equipped with coolant system, shortcut and overload protection,
7. Ideal choice for single pice, small batch and mass production for drilling, counter boring, reaming, tapping, spot facing, etc.
After-sale Service:
Technical support online service provided.
Technical files service provided.
Machine operation videl provided
On-site training service provided.
Spare parts replacement and repair service provided.
| Z3032×10 | |
| Model | |
| Max drilling cpacity(MM) | 32 |
| Distance from spindle center to column(MM) | max:980 |
| min:220 | |
| Distance from spindle nose to base(MM) | max:1000 |
| min:260 | |
| Spindle horizontal movement | |
| Spindle travel(MM) | 120 |
| Lifting speed | |
| Arm swivel angle | |
| Spindle taper | MT4 |
