14m Self Propelled Electric Scissor Lift Aerial Lift Platform Xg1412DC Price for Sale

Product Description

Product Description

Electric aerial lift platform XG1412DC developed by X C M G has the work height at 13.8m, the vehicle width at 1.19m, the rated load at 320kg and max. gradeability at 25%.
This kind of platforms are widely applied to warehouses, factories, airports, and train stations, especially the narrow work sites.
Advantages and features:
1.Effective and energy-saving electric-drive system features zero emission and low noise.
2.features compact structure, advanced performance, completed safety devices.
3.Meeting the customer needing for safety, reliability and intelligence.
4."Zero Turning Radius "is unique and enable machine to corner in narrow room.
5.Max. payload at 450kg, leading the industry. Maximum traveling speed 3.2km/h and 25% gradeability make the driving easier.

Detailed Photos
Product Parameters

Item	Unit	Parameters
Dimensions Length (without ladder)	mm	2477(2267)
Dimensions width	mm	1170
Dimensions Height (platform folded)	mm	2355(1805)
Wheel base	mm	1877
Wheel track	mm	1043
Min. Ground clearance (pit protector lifting / decline)	mm	100/20
Platform dimensions Length	mm	2277
Platform dimensions Width	mm	1120
Platform dimensions Height	mm	1263
Platform dimensions Platform extension length	mm	900
Vehicle center of mass position Horizonal distance from front axis	mm	950
Vehicle center of mass position Height of center of mass	mm	613
Total weight	kg	2620
Max. Platform height	m	8
Min. Platform height	m	1.2
Max. Working height	m	10
Min. Turning radius (inner wheel / outer wheel)	m	0/2.3
Platform rated load	kg	450
Extension platform rated load	kg	115
Platform lifting time	s	29-40
Platform decline tine	s	34-45
Max. Walking speed (low position)	km/h	4
Max. Walking speed (high position)	km/h	0.8
Max. gradeability	%	25
Tilt warning angle(side / forward and backward)	°	1.5/3
Lifting /walking motor Model	-	-
Lifting /walking motor Rated power	kW	3.3/0.75
Lifting /walking motor Manufacturer	-	-
Battery Model	-	T125/3-EV-225
Battery Voltage	v	24
Battery Capacity	Ah	225
Battery Manufacturer	-	Trojan/Leoch
Tire model	-	Non-trace solid/381×127

Packaging & Shipping
We supervise the process from the factory to the port designated by the customer to ensure that the customer's products arrive at the destination accurately and safely.
Our Advantages
Every year, we regularly attend the Canton Fair, the Philippines, Indonesia, Russia and other construction machinery and building machinery exhibitions.We have received more than 1000 clients and training engineers from more than 100 countries around the world.
We have already exported our products to more than 80 countries and regions, including: Africa, the Middle East, South America, Central Asia, Russia, Mexico, Australia, New Zealand, Holland, British, Mongolia and so on.
After Sales Service
we are famous building machinery manufacturer, professional construction machinery exporter and one stop solution supplier in China, our team have more than 15 years experience in this field already.
(1)Warranty:Every product issued shall enjoy a one-year/2000 working hour warranty period, during which we will repair or replace the defective parts free of charge if material or process defects occur and spare parts are in normal working condition.
(2)Spare parts:CANMAX is dedicated to provide our clients with genuine spare parts with the highest quality,exact fitness and appropriate function.with our global distributor network,you are guaranteed with fast deliveries and services, wherever you are,please submit your spare parts request to us,and list products name ,description of required parts.we guarantee that your request will be handled quickly and appropriately.
(3)Installation & Maintenance:CANMAX is able to provide with the overall installation of complicated machinery,allowing you to start the normal operation of construction machinery solutions.After installation,we will make inspection of the whole machine,operate equipment,and provide you with testing data reports of installation and operation.
(4)Training:CANMAX offer perfect facilities and comfortable environment and can provide training services to different users. The training sessions include product training, operation training, maintenance know-how, technical know-how training, standards, laws and regulations training and other training, all of which are tailored to fulfill your individual needs. Training programs can be conducted in our factory field, or at the client's site.
(5)Technical Advice: CANMAX can also help customers to coordinate with trained service personnel and provide you with detailed and extensive knowledge. Through our technical advice, your machine life can be significantly extended and sustained high capacity.
FAQ
Which countries do you export to?
Asia: India, Philippines, Thailand, Burma, Vietnam, Bangladesh, Kazakhstan, Turkmenistan, etc. Middle East: Saudi Arabia, UAE, Jordan, Oman, Pakistan, Qatar, etc. Europe: Russia, Ukraine, Belarus, Bulgaria, etc. Africa: South Africa, Kenya, Congo, Ethiopia, Nigeria, Ghana, Algeria, Senegal, Tunisia, etc. South America: Brazil, Peru, Chile, Cuba, Venezuela, Mexico, etc. Oceania: Papua New Guinea, Australia, etc.
What is the proportion of your products exported?
75% of our products are exported to all over the world.
What is the payment term?
Payment term is negotiable and there will be favorable payment terms for long-term customers. TT, L/C, D/P, depending on the cooperation time, country and contract value.

What kind of logistic service do you supply?
A. Transportation: railway transportation, international through transport, including (international railway through transportation, Sea-rail intermodal through transportation, sea-land multimodal transportation. Means of transport : Container, LCL, FRC, ro-ro, bulk cargo, train carriage, truck, air plane.
B. Term: FOB,CIF, DAP, to door service, etc.

What spare parts can you supply?
All kinds of spare parts of SHANTUI, ZOOMLION, SINOTRUCK, SHACMAN, LIUGONG, SAN Y, SDL G, LONKING, XGMA, CUMMIN S ENGINE, ZF GEAR BOX, etc.
