High Speed Multi-Cylinder Hydraulic Stone Portable Pyb Spring Cone Crusher

Product Description

Product Introduction
CS series high-efficiency spring cone crusher is used in the ferrous and non-ferrous metal beneficiation process. It can effectively reduce the particle size of the ore entering the mill, achieve more crushing and less grinding, which not only improves the production capacity of the mill, but also saves electricity and steel, and greatly improves the economic benefits of the mine.
CS series spring cone crusher is suitable for crushing medium-hard ores and rocks. It has the characteristics of reliable structure, high production efficiency, convenient adjustment and economic use. Its spring safety system plays an overload protection role, allowing super-hard foreign matter (such as iron blocks, etc.) to pass through the crushing chamber without damaging the machine. It adopts two sealing forms, dry oil or water, to isolate the stone powder from the lubricating oil and ensure the reliable operation of the machine. The crushing chamber type is determined by the particle size of the finished material. The standard type is used for medium crushing operations, and the medium and short head types are used for fine crushing operations.
Product Advantages1. Inheriting the classic structural design, stable and reliable performance. The reason why the spring cone crusher has become a widely used cone crusher at home and abroad is due to its reliability in working under various working conditions. The compound cone crusher retains the classic structure, and the reliability of the equipment is guaranteed to a large extent.
2. A variety of cavity types are available for selection, and there are two types of standard and short-head types for various working conditions. Each type is equipped with a variety of cavity types, which can be applied to the medium and fine crushing of various hardness materials.
3. Laminated crushing design, good particle shape of the output material, using the laminated crushing principle to crush the material, high crushing efficiency, low wear of wearing parts; the finished product after crushing is cubic, with a high fine particle content, which can well meet the current use needs of some high-quality aggregates.
4. Long service life and wide application range. The body and accessories are made of high-quality steel, which effectively reduces the damage of the material to the body and accessories, and can crush dozens of materials
Working Principle
When the crusher is working, the motor drives the eccentric sleeve to rotate through the elastic coupling, the transmission shaft and a pair of bevel gears. The crushing cone is driven by the eccentric sleeve to make a swinging motion, so that the crushing wall and the mortar wall are sometimes close to each other and sometimes far away from each other. The ore is constantly squeezed and impacted in the crushing chamber and is crushed.
CS Series High-Efficiency Spring Cone Crusher Technical Parameters

Model	Movable Cone Diameter (mm)(inch)	Cavity	Feed Opening(mm)		Outlet Size Can Be Adjusted (mm)	Capacity (t/h)	Motor Power (kw)	Weight (t)	Overall Dimension (mm)
			Closed Size (mm)	Opening Size (mm)
CS75B	900	Fine	83	102	9-22	45-91	75	15	2821 × 1880 × 2164
		Coarse	159	175	13-38	59-163
CS110B	1200	Fine	127	131	9-31	63-188	110	20	2821 × 1974 × 2651
		Medium	156	156	13-38	100-200
		Coarse	178	191	19-51	141-308
CS160B	1295	Fine	109	137	13-31	109-181	160	27	2800 × 2342 × 2668
		Medium	188	210	16-38	132-253
		Coarse	216	241	19-51	172-349
CS220B	1395	Fine	155	173	19-45	120-200	220	31	3360 × 2650 × 3050
		Medium	188	198	22-50	150-300
		Coarse	230	245	25-65	200-400
CS240B	1650	Fine	188	209	16-38	181-327	315	55	3911 × 2870 × 3771
		Medium	213	241	22-51	258-417
		Coarse	241	268	25-64	299-635
CS400B	2134	Fine	253	278	19-38	281-726	110	110	4613 × 3251 × 4732
		Medium	303	334	25-51	608-998
		Coarse	334	369	31-64	789-1270

Application areas
river pebbles, granite, basalt, iron ore, limestone, quartz, diabase, iron ore, gold ore, copper ore, etc.
