30tph Palm Oil Processing Machine and Crude Palm Oil Refining Production Line for Sale

Product Description

Company Profile
Henan Huatai Cereals and Oils Machinery Co., Ltd. has more than 30 years of experience in cereals and oils machinery manufacturing. We have a complete turnkey system in large-scale oil production line projects, we master EPC engineering, oil pre-pressing engineering, extraction engineering, refining engineering to filling equipment and PLC automatic control system, and finally realize that customers can operate independently. We have rich experience in oil engineering.

Product Description
Palm oil processing machine plant and palm oil refinery plant
We are professional Chinese palm oil machines manufacturer, we can offer turnkey project. The capacity of our palm oil mill: 1TPH-90TPH.
The main palm oil mill processing includes following station:
Reception station, sterilizing station, threshing station, digesting station, pressing station, clarification station, depericarping station, kernel recovery station, boiler house, etc.

Reception station: Used for loading palm fruit brunch from plantation, transport to sterilizer,Reception station adopt steel structure and concrete structure. Save equipment cost and construction cost. Have hydraulic control system,hydraulic door open/off automatic achieve continuous operation. Reduce operator,operate more easily and improve work efficiency.

Sterilization station: The sterilizer works with direct steam, the steam can weaken the activity of the enzyme, prevent it getting rancid, ensure the good quality of the crude oil. At the same time, it is good for the following threshing processing. We have designed both horizontal and vertical sterilizer, for larger and smaller line.

Threshing station: The rotating of the drum in the thresher can separate the fruit from the bunch. The fruit will be conveyed to the digester through elevator, and the empty bunch will be conveyed to the outside part through scraper conveyor. The spindle adopts once forging technology, which can make the equipment more solider and durable. At the same time, we have already designed the non spindle thresher, which is driven by the link chain. It can save the producing cost in a large scale.

Digesting station: The digester is used to adjust the moisture and temperature of the fruit,finally it can increase the oil extraction rate. The digester adopts liquid level control system, which can distribute the material all by itself. To realize the automatic working. The presser adopts hydraulic control system to adjust the distance of different pressing worms, it is applicable to different kinds of palm fruits, and it can ensure the high oil extraction rate.

Pressing station: The palm fruit oil yield increase by adjusting material moisture and temperature in digesting tank.digesting tank uses liquid level control, so material can distribute automatically and equipment runs fully automatically. Pressing machine uses hydraulic control system to adjust spacing between pressing bolts. So it can be suitable for various palm fruit species and guarantee the oil yield.

Clarification station:Using the latest technology, under the condition of ensuring the good quality of the oil, reduce the equipment cost as much as possible, reduce the loss of the oil, in the practical producing ,the new technology can make the loss of oil less than 1.3%.

Packaging & Shipping
FAQ
1. who are we?We are based in Henan, China, start from 2004,sell to Domestic Market(30.00%),Eastern Asia(25.00%),Africa(20.00%),Eastern Europe(8.00%),South America(5.00%),Mid East(5.00%),South Asia(2.00%),Southeast Asia(2.00%),Oceania(1.00%),Northern Europe(1.00%). There are total about 201-300 people in our office.2. how can we guarantee quality?Always a pre-production sample before mass production;Always final Inspection before shipment;3.what can you buy from us?Oil Pressing; Extraction And Refining Equipment; Palm Oil Machine; Soybean Oil Machine; Sunflower Oil Machine; Cottonseed Oil Machine4. why should you buy from us not from other suppliers?Henan Huatai Cereals and Oils Machinery Co.,LTD is a large-scale oil machinery manufacturing company integrating R&D, design, manufacture and installation for over 30 years production experience, which is one of the largest oil equipment supplier in China.5. what services can we provide?Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP;Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;Accepted Payment Type: T/T,L/C,Western Union,Cash;Language Spoken:English,Chinese,Spanish,French,Russian
