Bench Strong Drilling Machine (D-32G)

Product Description

Bench Strong Drilling Machine

PART 1---Product Description
FEATURES: * Attractive, elegant, pleasing design;
* Reasonable structure, high rigidity, high strength;
* Long spindle travel, wide machining range;
* Worktable can rise/down by rack/handle, 360 degree rotation, easy to opreate and
mechanical advantage;
* Spindle head, worktable, column and base use high quality casting
processed by aging treatment, stability and duarable in use.
* Spindle, spindle sleeve, gear shaft processed by heat treatment and hardened.
PARAMETER:

Model	D-16G	D-20G	D-32G
Max. drilling capacity	16 mm	20 mm	31.75 mm
Max. tapping capacity (Iron/steel)	M12/M10	M20/M16	M24/M20
Column diameter	50 mm	50 mm	100 mm
Spindle travel	100 mm	135 mm	150 mm
Distance from spindle to column	193 mm	260 mm	265 mm
Distance from spindle to worktable	330 mm	366 mm	390 mm
Distance from spindle to base	613 mm	678 mm	745 mm
Spindle taper	MT2	MT3	MT3
Sindle speed range	5 steps, 320~2730 rpm	5 steps, 290~2150 rpm	5 steps, 280~1875 rpm
Table size	265×285 mm	300×320 mm	380×400 mm
Base Size:	360×480 mm	376×566 mm	645×470 mm
Motor power	0.55 kw	1.1 kw	1.5 kw
zztimac.en.made-in-china.com weight	145kg	170kg	225kg
Packing size (L×W×H)	780×450×1260mm	970×490×1390mm	1000×600×1500mm

PART 2 ---Our Service

1. Free replacing parts available in the warranty period.
Cost price replacing parts available beyond the warranty period.
2. Quick action and reply for the technical questions at any time in the whole life of the machine.
3. Overseas after service center available in some region.
4. Engineer overseas service available on the requirement of customer(relative cost born by customer).




Part 3---Company Information

"TIMEWAY MACHINE" is a registered Chinese business business located in Zhengzhou city, in the center of China, and has been opearting in the machinery industry for many years.

Our factory is the joint-stock enterprise, founded in 1946, has 50 years of machine tool manufacturing history.Occupies more than 500acres, built a foundary, machining, heat treatment, assembly, quality inspection, painting, logistics and other advanced production lines.

Our product mainly cover lathes, Milling, Drilling, Gringding, Sawing, Shaping/Slotting and related accessories&tools, etc.
Packaging & Shipping
Company Profile
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
Customer visited
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
The following is one of the most satisfactory products recommended by customers, as well as our main product categories. you can click and view

Conventional Lathe	CNC Lathe	CNC Machining Center	CNC Milling Machine
Grinding Machine	Milling Machine	Special Use Lathe	Boring Machine

FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;
Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.
Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )
Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.
Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
