X715 Heavy Cutting Swivel Head Bed Type Universal Milling Machine for Sale

Product Description

X715 heavy cutting swivel head bed type universal milling machine for sale
Product Application

The main specification :

Model	unit	specification X715
TABLE :
Table size	mm	2100x500
T slot	no	4
Size ( Width )	mm	20
Centre distance	mm	100
Max. load of Table	kg	2000
machining range :
Longitudinal travel	mm	1500
Cross travel	mm	670
Vertical travel	mm	670
MAIN SPINDLE :
Spindle taper		ISO50 7:24
spindle speed /step	rpm	35-1345/12
distance from spindle axis to column surface	mm	610
distance from spindle nose to table surface	mm	0-670
FEEDS :
Longitudinal/cross feed	mm / min	20-1800/stepless
Vertical		10-900/stepless
Longitudinal/cross rapid speed	mm / min	3500
Rapid Traverse vertical		1750
POWER :
main motor	kw	7.5
feed motor	kw	2
coolant motor	w	550
others
package dimension	cm	228x228x282
overall dimension	cm	330x238x275
machine weight	kg	7300

The Machine features:
1.X715 bed type universal milling machine is with universal milling head.The head can swivel 360 degrees.It can perform both vertical and horizontal milling.
2.The machine is with servo motor, and three axes are automatical feed.It's with rectangular guideways with high stability
3.The machine is equipped with automatic lubrication system.
4.The machine is bed type milling with large load and suitable for machining large worpieces.
Product Details
Packing shipping
For machine: usually by sea;
For documents: by international express, eg. DHL,TNT or EMS.
For packing :Free fumigation plywood packaging steel base
our service
1. Technical support online service provided.
2. Technical files service provided.
3. Machine operation video provided
4. On-site training service provided.
5.Spare parts replacement and repair service provided.
6 All of the questions will be replied within 8 hours
7. If you need to develop products with your own specification, we can help you to work it out.
8. Always be honest, never lie to customer, and never declare anything we don't have
Company Information
Since 1996,20 years' history for machine tool manufacturing
10 years' history for export
Total 2 manufacturing bases in china
Sino-germany technology cooperation
Production of 8 categories, more than 130 kinds of products
Set up design&research center at TAIWAN
Exported to total 48 countries in the world covered most areas
One-stop shopping for nearly all other types' machine tools

1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
3: Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277500 China. You are warmly welcomed to visit us.
4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
6: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )

We want to know:
1.What's your Industrial Voltage?
2.We strongly suggest you to tell us size, material of your workpiece for our evaluation, if possible, better to send us workpiece drawing, so that we can recommend you most suitable model!
3.If need CIF Price, please kindly tell us the port of destination.
