Mini DC UPS Dcf-120W for CCTV Camera Output 12V*10
| US$36.50-58.10 | 100 Pieces (MOQ) |
Basic Info.
Model NO.
DCF-120W
Protection
Short Circuit
Application
Communication
Classification
Lighting/Power
Standby Time
Standard Machine
Standby UPS
Online
Output Capacity
Small Type
Equipment Mode
Classification
Brand
Andespower
Battery Type
Lithium-Ion or LiFePO4 Battery
Battery Numbers
4 or 8
Capacity
8000mAh-52000mAh
Display
LCD
Color
Silver Gray
Warranty
1 Year
Transport Package
Carton
Specification
214*158.5*86mm
Trademark
Andespower
Origin
Guangdong China
HS Code
8504402000
Production Capacity
50000pieces/Month
Product Description
Features:
1) The cool electrical appearance, small size, high performance, stable parameters and rich practicality all in one;
2) Built-in adapter, widely AC input voltage range;
3) The ups has DC input, it also can be used with an external power adapter or solar panel;
4) Unique battery compartment design, it supports various capacity of lithium battery packs, the capacity can be expanded up to 165Wh, the back-up time will be longer.
5)High compatibility, built-in more DC voltage output, and it with a variety of interfaces, which can be used more widely. Such as mobile phone, wireless charging, IPAD, MP4, router, wireless WIFI bridge, Network switch, home humidifiers, CCTV, fingerprint machines etc.
6) LCD display for the working status of the machine;
7) DCF100W/DCF120W is designed by wall mounted type and tower type.
8) The built-in silent combined fan adopts intelligent speed control, which is quiet.
9) Full protection, it has discharge, overcharge, over current, overload, over temperature and short circuit protection.
Specifications:
| Model | DCF-100W | DCF-120W |
| Input | 100 ~ 240Vac 50/60Hz | |
| 12 ~ 24Vdc(2.5A) | ||
| Output | 5VDC + USB x2 (2.4A) | 5VDC + USB x2 (2.4A) |
| 1 x 9V/12V (2A) (selectable) | 1 x 9V/12V (2A) (selectable) | |
| 10 x 12V(8A) | 10 x 12V(10A) | |
| Output power | 100W | 120W |
| Battery capacity | 8000mah~52000mah (selectable) | |
| Battery numbers | 4 or 8 (selectable) | |
| Battery type | 18650(Lithium-Ion/LiFePO4) or 32700(LiFePO4) (selectable) | |
| Operation temperature in working mode | 0-40ºC | |
| Operation temperature in discharge mode | 0-50ºC | |
| Unit dimension (mm) | 214 X 158.5 X 85 | |
| Net Weight (kg) | 1.85(max) | |
Product Review:
Front View
Rear View
Application
Company Profile
Certificates
