with Lower Price Hyundai 26ton Crawler Excavator Xe260cll

Product Description

Hydraulic long reach excavator for sale hyundai XE260CLL
1. Operation weight: 27500kg
2. Long boom 16.5m with Standard 0.4 m3 bucket
3. Max. Digging height: 13800mm
4. Original KAWASAKI hydraulic system
5. Engine: Japan ISUZUs 128.5kw
6. Original KAWASAKI electronic system
7. Cabin with A/C, ROPS/FOPS
8. With break hammer
hyundai hydraulic crawler excavator XE260CLL (equipped with extended longer boom 16.5m) with Japan ISUSU engine and has operation weight of 27500kg. It has strong performance in building construction and can be used in mine with hydraulic hammer to break stones into small ones for further processing in crushing plant.
Japan KAWASAKI hydraulic system and electronic system has provided XE260CLL excavator with reliable and excellent performance.
1. Imported engine of environment friendly and efficient low-consumptions
2. Complete set of imported hydraulic components, excellent control, smooth operation
3. Imported radiator, adapt super load and continuous operation
4. High quality key parts, the chassis configuration of international quality
5. Powerful digging force, slew force and traction force
6. Completed closed PROS / FOPS cab, good vision and protection structure, import luxury seats, safe and comfortable
7. Fast full-open style hood, easy maintenance
8. Anti-collision structure of cast iron weight, the effective protection of turntable and hood
9. Optional hydraulic breaker piping, to facilitate the crushing operation
Technical Parameters

Model		Unit	XE260CLL
Operating weight		kg	27500
Standard bucket capacity		m³	0.4
Engine	Engine Model	/	ISUZUs CC-6BG1TRP
	Direct injection	/	√
	Four strokes	/	√
	Water cooling	/	√
	Turbo charged	/	√
	Air to air intercooler	/	√
	No. of cylinders	/	6
	Rated power/speed	kw/rpm	128.5/2100
	Max. torque/speed	N.m	637/1800
	Displacement	L	6.494
The main performance	Travel speed	km/h	5.5/3.3
	Swing speed	r/min	12.1
	Max. gradeability	/	≥30
	Ground pressure	kPa	40.8
	Max.Bucket digging force	kN	70.7
	Max.arm crowd force	kN	41.3
	Max.traction force	kN	193
Hydraulic system	Main pump	/	2 Gear Pump
	Rate flow of main pump	L/min	2×231
	Max pressure of prime relief valve	MPa	32.3/34.4
	Max pressure of travel system	MPa	34.3
	Max pressure of swing system	MPa	23
	Max pressure of pilot system	MPa	3.9
Oil capacity	Fuel tank capacity	L	400
	Hydraulic tank capacity	L	240
	Engine lubrication	L	25
Overall dimensions	A Overall length	mm	13900
	B Overall width	mm	3390
	C Overall height	mm	3360
	D Overall width of upperstructure	mm	2830
	E Track length	mm	4640
	F Overall width of undercarriage	mm	3390
	G Crawer width		800
	H Track length on ground	mm	3842
	I Crawer gauge	mm	2590
	J Clearance under counter weight	mm	1050
	K Ground clearance	mm	495
	L Min.tail swing radius	mm	2985
Working range	A Max. digging height	mm	13800
	B Max. dumping height	mm	11414
	C Max. digging depth	mm	14915
	D 8inch horizonal digging depth	mm	×
	E Max. vertical wall digging depth	mm	13917
	F Max. digging reach	mm	18258
	G Min. swing radius	mm	6740
	Angle of arm deflection	Degree
