High Performance Offroad Winch 12000lb

High Performance Offroad Winch 12000lb

US$167.00 32 Pieces (MOQ)

Basic Info.

Model NO.
STD12.0
Pull Direction
Backward
Electric Winch Model
Std12000s
Working Voltage of Electric Winch
DC12V
Certification
CE
Transport Package
Carton and Wooden Pallet
Specification
12000lb
Origin
Zhejiang
HS Code
8425319000
Production Capacity
40000/Year

Packaging & Delivery

Package Size
60.00cm * 35.00cm * 27.00cm
Package Gross Weight
38.000kg

Product Description

High Performance Offroad Winch 12000LB
SPECIFICATION:
Line Pull: 5,443kgs/12,000lbs
Motor: 12V / 6.0hp
Gear Train: Three stage
Gear Ratio: 265:1
Free-spooling Clutch: Rotating ring gear
Synthetic Rope Size: Φ3/8"×90'(Φ9.5mm×27m)
Drum Size: Φ2.5"×8.8"(Φ64mm×224mm)
LINE PULL
Layer of Wire Rope Max Line Pull
1 12,000lbs/5,443kgs
2 10,270lbs/4,658kgs
3 9,200lbs/4,173kgs
4 8,450lbs/3,833kgs

LINE SPEED AND AMP DRAW (1st layer of rope on the drum)
Load Line Speed AMP Draw(12V)
No Load 31.8FPM/9.7MPM 75
4,000lbs/1,814kgs 21.6FPM/6.6MPM 195
6,000lbs/2,721kgs 17.7FPM/5.4MPM 240
8,000lbs/3,628kgs 13.4FPM/4.1MPM 291
10,000lbs/4,536kgs 11.2FPM/3.4MPM 335
12,000lbs/5,443kgs 7.9FPM/2.4MPM 350

DIMENSIONS
534 x 163 x 225mm (21.0" x 6.3" x 8.9")
STANDARD ACCESSORIES
Controller
Synthetic Rope With Hook
Hawse Fairlead
Control Unit
Mounting Hardware
Hand-saver Strap
PACKAGE
Winch Weight: 36kgs/79.2lbs
Gross Weight: 38kgs/83.6lbs
Box Dimension: 600×245×370 mm (23.6"×9.6"×14.6")
