Hydraulic Sheet Cutting Machine

Hydraulic Sheet Cutting Machine

US$80,000.00-150,000.00 1 Set (MOQ)

Basic Info.

Model NO.
Customzied
Certification
CE, ISO 9001:2000, ISO 9001:2008, RoHS
Condition
New
Warranty
1 Year
Gap Between Upper and Lower Blade
70mm (Empty Gap Could Be Higher)
Blade Length
2600mm(Customized Size Contact with Supplier)
Transport Package
Plastic Film
Specification
50*2500mm
Trademark
jsyzsk1
Origin
Yangzhou
HS Code
8462330000
Production Capacity
100sets Per Year

Product Description


Hydraulic sheet cutting machine
Product Description
Main technical parameters of this Hydraulic sheet cutting machine:
No. item parameter unit
1 Blade clearance 70 mm
2 Max. Cutting thickness(carbon steel) 50 mm
3 Max. Cutting thickness(stainless steel) 25 mm
4 Max. Cutting width 2500 mm
5 No. of stroke 5 times/min
6 Blade length 2600 mm
7 Cutting angle 1°30′-4° angle
8 Back gauge distance adjustment 20-1000 mm
9 Main motor model Y132M-4
10 Main motor power 55 Kw
11 Overall Dimensions 3350*2550*3550 mm
12 The weight of machine about 45T Ton

Main configurations of this Hydraulic sheet cutting machine:
Main motor, Simens Low noise gear pump Blade clearance control
Oil cylinder Spherical support Fence
Electrical components AC motor Workbench

Main configuration list of this Hydraulic sheet cutting machine:
No. Item
1 Oil pump, low noise gear pump, Chengjie, China
2 Valve, Yeer, Shanghai, China
3 Electrical components, Schneide, France
4 Tubing, EMB, Germany
5 Blade material:6Crw2si
6 Ball screw linear guide, Hiwin,Taiwan,
7 E21S controller,China(DELEM DAC310T,DAC360T optional)
8 Rapid and precise blade clearance adjustment by single handle on the side frame or electric control
9 Multi Edge Blades for cutting Aluminium, Mild Steel and Stainless Steel
10 Cutting Line Illumination and wire for shadow line cutting
11 Counter of Strokes, Cutting Length Adjustment
12 Hydraulic and Electrical overload protection
13 Squaring Arm and Front Support Arms
14 Delta inverter with ball screw and polished rod with 0,05 mm accuracy.
15 Light guards(option )
16 Backguage pneumatic support(optional)
Notes :Above items could be instead by the same level brands if the delivery time is urgent . Packaging & Shipping
Company Profile Our company:
Jiangsu Yizhong CNC Machine Tool (Group) Co., Ltd is a Top machine tool factories for plate processing in China, which set up in 2006, located in Chengbei industrial area, Yangzhou city, Jiangsu province. It covers an area of 498700 square meters and nine production lines. We' re also the National Torch Plan and High-tech enterprise.
Our main products includes Hydraulic guillotine shearing machine ,Plate rolling mchine (also production line ),Plate hydraulic press machine ,Plate leveling machine ,and plate planer and milling machine . Meanwhile , with a powerful technician team, OEM machine is our strong suit .
With many years' hard-working, we have built long term and close cooperation relationships with many friends, such as Russia, Australia, United Kingdom, Italy, South Americas, Egypt, India and so on,welcome
your consulting
