Growatt/Deye/Sungrow 3kw 5kw 10kw 20kw 48V Solar Sine Wave off Grid Inverter with MPPT Solar Charger

Product Description

Product Description
Product display Product Parameters DATASHEET MID 15KTL3-X MID 17KTL3-X MID 20KTL3-X MID 22KTL3-X MID 25KTL3-X

Noise emission (typical)	≤40 dB(A)	≤40 dB(A)	≤40 dB(A)	≤40 dB(A)	≤40 dB(A)
Interfaces: USB/RS485/WIFI/GPRS/4G	yes/yes/opt/opt/opt	yes/yes/opt/opt/opt	yes/yes/opt/opt/opt	yes/yes/opt/opt/opt	yes/yes/opt/opt/opt
DC reverse polarity protection	yes	yes	yes	yes	yes
DC Switch	yes	yes	yes	yes	yes
Ground fault monitoring	yes	yes	yes	yes	yes
Output short circuit protection	yes	yes	yes	yes	yes
DC Surge protection	Type II	Type II	Type II	Type II	Type II
AC Surge protection	Type II	Type II	Type II	Type II	Type II
Topology	Transformer less	Transformer less	Transformer less	Transformer less	Transformer less
Cooling concept	Smart cooling	Smart cooling	Smart cooling	Smart cooling	Smart cooling
String monitoring	opt	opt	opt	opt	opt
AFCI protection	opt	opt	opt	opt	opt
Display	OLED+LED WIFI+APP	OLED+LED WIFI+APP	OLED+LED WIFI+APP	OLED+LED WIFI+APP	OLED+LED WIFI+APP
Environmental Protection Rating	IP65	IP65	IP65	IP65	IP65
DC connection	H4/MC4(opt)	H4/MC4(opt)	H4/MC4(opt)	H4/MC4(opt)	H4/MC4(opt)
Max. efficiency	98.5%	98.6%	98.6%	98.7%	98.7%
Euro - eta	98.1%	98.2%	98.2%	98.3%	98.3%
Nominal voltage	580V	580V	580V	580V	580V
Dimensions (W / H / D) in mm	525/395/222	525/395/222	525/395/222	525/395/222	525/395/222
AC grid frequency; range	50/60 Hz; 45~55Hz/55-65 Hz	50/60 Hz; 45~55Hz/55-65 Hz	50/60 Hz; 45~55Hz/55-65 Hz	50/60 Hz; 45~55Hz/55-65 Hz	50/60 Hz; 45~55Hz/55-65 Hz
Altitude	4000m	4000m	4000m	4000m	4000m
Max. output current	24.2A	27.4A	31.39A	35.5A	40.2A
AC grid connection type	3W+N+PE	3W+N+PE	3W+N+PE	3W+N+PE	3W+N+PE
Max. recommended PV power (for module STC)	19500W	22100W	26000W	28600W	32500W
Max. short circuit current per MPPT	32	32	32	32	32/48
Max. AC apparent power	16600VA	18800VA	22000VA	24400VA	27700VA
Start Voltage	250V	250V	250V	250V	250V
Rated AC output power	15000W	17000W	20000W	22000W	25000W
Max. input current per MPPT	25	25	25	25	25/37.5
Weight	23kg	23kg	23kg	23kg	23kg
AC nominal voltage; range	230V/400V; 340-440V	230V/400V; 340-440V	230V/400V; 340-440V	230V/400V; 340-440V	230V/400V; 340-440V
MPPT voltage range	200V-1000V	200V-1000V	200V-1000V	200V-1000V	200V-1000V

Successful Project Packing And Delivery Package &Payment
Before installation, kindly inspect the unit thoroughly. Ensure the contents within the package remain unharmed. Your package should contain the following items:
FAQ
1. How can we guarantee quality?
We utilize the latest cutting-edge, fully automated production equipment to uphold the pinnacle of quality standards.
Our meticulous, step-by-step final inspection system ensures that every product undergoes rigorous vetting before it is shipped.
2. What can you buy from us?
Discover our extensive offerings: Solar Panels and comprehensive system sets specifically tailored to accommodate your every need.
3. Are you manufacturer? Or trade company?
We are a distinguished Manufacturer, steadfast in our commitment to excellence.
4. What services can we provide?
We offer a variety of Delivery Terms including FOB, CIF, EXW, and Express Delivery for your utmost convenience.
We accept payments in a variety of currencies: USD, EUR, HKD, CNY, and beyond.
For payment, our accepted methods are T/T and Cash.
Our team is proficient in multiple languages, including English, Chinese, and French, to better assist you.
5. What is the lead time?
Typically, orders are processed and prepared for dispatch within a swift timeline of 15 working days following receipt of advance payment. Why Choose Us
Anhui Kimi New Energy Co., Ltd (Kimi Solar)is a premier professional manufacturer with over 15 years of distinguished expertise in the Solar Panel industry, synonymous with quality and innovation.
Our rich and diverse product lineup encompasses poly and mono solar panels, solar batteries, power systems, charger controllers, inverters, lights, and even solar air-conditioning. We specialize in custom solar system solutions, proudly serving clients across more than 60 countries throughout Europe, Asia, the Americas, and Africa.
Partner with a name you can trust. Our global presence extends across Australia, Africa, Russia, the Middle East, South America, Asia, and beyond. Join us for a rewarding and prosperous business partnership!
