Clean-Link Manufacturer Customized Glass Fibre Materials with Clapboard HEPA Air Filter

Product Description

Specifications
High Efficiency Mini Pleat H13 HEPA Filter
1) different sizes available
2) filtrration grade: H13/H14
3)small resistance

Speciality:
Hight quality glass fibre paper;
Glass fibre papoer is folded into closely sapced shallow pleats ,with textile thread spacers to ensure an optimum pleating geometry;
Efficiency from 99.99%;
Laser testing one bye one, Temp. resistance up to 80, small resistance ,high efficiency, long service life ;

Using:
Applied to the terminal filtration of the air-condition filtration system
Suitable for hospital ,electronic industry, food , precision instrument, electron semiconductors and dust-free room,etc.

Specification:

	Outside size (mm)	Rated air flow	Dust holding capacity g	Initial resistance (Pa)	Filtration efficiency
CHP	1220*610*100	2600	1600	≤220Pa (22.4mmH 2 O)	99.99% 0.3μM
	915*610*90	1900	1200
	610*610*80	1300	800
	915*610*69	1500	950
	610*610*69	1000	650
	915*610*50	1100	700
	610*610*50	700	450
CHU	610*610*50	470	450	≤170Pa	99.9995% (0.1-0.2μm)
	915*610*50	700	700
	610*610*69	600	650
	610*610*90	800	800
	915*610*90	1200	1200
	1220*610*100	1600	1600

Related Products Related Products

Related Products

Production Application
Pre-filtration and second filtration for the ventilation system of the air condition;
The filtration for entering or returning the air in the clean room.
