Jinzong Coffee Powder Mixer Mixing Machine

Jinzong Coffee Powder Mixer Mixing Machine

US$15,000.00
1-4 Pieces
US$1,000.00
5+ Pieces

Basic Info.

Application Area
Daily Chemical
Certification
CE, ISO
Condition
New
Stirring Type
Gravity
Working
Convection Mixer
Capacity
5-300L
Voltage
Customized
Application Porducts
Coffee Powder, Facial Powder, Cosmetic Powder
Mixer Type
Powder Mixer
Layout Type
Horizontal
Mixing Drum Shape
Conical
Operating type
Continuous Operating
Transport Package
Wooden Case
Specification
CE, SGS
Trademark
JINZONG MACHINE
Origin
Guangdong, China
Production Capacity
50sets/Month

Product Description

Food & Cosmetic Machine: V-shape mixer
1.Mix dry powders or granules
2.Eveness to 99%
3.Conform to GMP standard

2.Food & Cosmetic Machine V-shape mixer is suitable for mixing the dry powder and granule which belong to flowing materials. The machine consists of two asymmetric barrels where the materials would be moved longitudinally and transversely so that the mixing evenness can be over 99 percent. The mixer can be equipped with vacuum suction system with which the materials can be sucked into the mixing barrels and mixed under hermetic condition. There is no driving mechanism inside the mixer so that it is very clean and meets GMP standard.
3.Parameter of Laboratory V shape Mixer:
V-shape Mixer
Type Design Capacity Working Capacity Power Speed(r/min) Size(mm) Max Loading Capacity Weight(kg)
VH5 5L 2L 0.55kw 24r/min 515*430*650mm 2kg 50
VH8 8L 3.2L 0.55kw 24r/min 620*520*660mm 2.5kg 60
VH14 14L 5.6L 0.55kw 20r/min 1000*460*920mm 4kg 90
VH20 20L 8L 0.55kw 20r/min 1250*350*1100mm 6kg 120

4.Parameter of Big Scales Production V shape Mixer:
V-shape Mixer Specification
type VH-100 VH-300 VH-500 VH-1000 VH-1500 VH-2000 VH-2500 VH-4000
Production Capacity 30 80 100 200 300 400 400 800
(kg/h)
Pump type W2 W2 W3 W3 W3 W4 W4 W5
Feed time(min) 4-6min 6-9min 6-10min 12-18min 12-18min 12-18min
Mix time(min) 4-8min 6-10min 6-10min 6-10min 6-10min 6-10min 6-10min 6-10min
Vol.(m3) 0.1 0.3 0.5 1 1.5 2 2.5 4
Speed(r/min) 12 12 10 10 10 10 10 8
Motor Power(kw) 1.1 1.1 2.2 4 4 7.5 7.5 11
Dimension 1780×650×1750 1800×650×1850 2500×1220×2420 2975×1600×3000 3190×1600×3000 3800×1900×3310 3990×1990×3790 4945×2200×4230
(LWH)(mm)
Height 1750 1850 2450 3000 3100 3700 3790 4160
Weight(kg) 250 320 550 950 1020 2000 2040 2800
