High Productivity PLC Crochet Machine

Product Description

High Productivity PLC Crochet Machine
Product Description
VG-980 Crochet Machine
VG-980 model is a traditional high speed fancy yarn crochet knitting machine, first kints cloth with warp and weft yarn, then cuts the warp yarn to form the final yarn.otherwise it kints warp and weft yarn the straightly kit belt yarn.
VG-980 machine is suitable to knit various kind of yarns,both natural fibers(wool,silk,cotton, linen,etc) and synthetic fibers(polyester,acrylic etc)This entire material can de dyed before of after knitting,in accordance with the requirements.The characteristic of the patter yarn is the core yarn knitted into ring and the weft one used as its mattress.The finished yarn is of flat shape.
Features:
1.The patent structure increases the capacity about more 2~7 times than the old type,without widening the operation width.
2.The newly designed cam lowers the noise and extends the machine lifetime.
3.The optimized structure of the machine lengthens the further of the yarn and fasten the futher making the further being not falling off,even if intentional ly pulled by hand.

VG-980B Crochet Knitting Machine
VG-980B type crochet machine is a new type of crochet machine developed by our company on the basis of extensive absorption of customer experience and similar models. It is an upgraded model of VG-980 type crochet machine in our company and has obtained the national patent. Can greatly increase the speed and output of the whole machine without changing the width of the whole machine.
The advantages of the general 980 are as follows:
·Using servo motor weft feeding, weft feeding speed is higher, more accurate;
·Use touch screen to set process parameters, the replacement process is more convenient and flexible;
·The key parts are imported high quality bearings, the precision is higher, the production speed is higher, and the output is increased more significantly.

Product Parameters

Model	VG-980	VG-980B
Operational width	762mm	762mm
Gauge needle per inch	15G,18G,20G	10G,15G
Weft density range	5~20s/cm	5~20s/cm
Main shaft speed	1200r/min	1800r/min
The girth of rack frame	170cm	170cm
Full power	1.56KW	2.31KW
Yarn creel count	260	260
Yarn creel distance	200mm	200mm
Shape size (length × width × height)	Main machine: 1750 × 1950 × 1750 (mm) Winding section: 2300 × 2790 × 2400(mm) Yarn frame(1):2100 × 1880 × 2750(mm)
