Napkin Folding Machine with 2 Color&2 Embossing

Napkin Folding Machine with 2 Color&2 Embossing

US$1.00-15,500.00 1 Set (MOQ)

Basic Info.

Model NO.
CJ-A
Control
Automatic
Embossing Type
Full-Embossing
Embossing Roller
Steel Roller
Tissue Packaging
Bag
Function
Folding
Tissue Type
Mini
Transport Package
Wooden Case
Specification
CJ-A
Trademark
Yibang
Origin
Foshan City Guangdong Province China
HS Code
8401200000
Production Capacity
100 Sets/Year

Product Description

Product Description
Machine details
Feature:
1.Adopts professional embossing roller.
2.When the raw paper is ready , it will be sent to the embossing unit then printing unit(Optional order).
3.Machine will stop automatically if the paper jammed the folding roll.
4.With steel to rubber embossing unit, embossing can be steel to wool roller, steel roller or rubber roller( choose one).
5.The gap between two folding&cutting rollers can be adjustable according to different plies and GSM.
6.*Steel to steel embossing roller can be added on machine.
7.*Engraved embosser can be added on machine.
8. *Automatic constant temperature heating unit on embosser unit can be ordered.
Specification:
Max.width of raw paper 270mm Other sizes to be specified
Max.Outer Diameter of raw paper φ1100mm
Open Size Of Finished Product 270*270mm Other sizes to be specified
Machine Speed 600-650pcs/min
Max.speed 680pcs/min
Raw paper Material 1-3 plies tissue paper with 18-25GSM each ply
Folding style 1/4fold (Other folding style need to be ordered)
Printing NA/1 color/2 colors, flexo printing, water-based ink ,aniline plate
Embossing Unit Steel to rubber/Steel to wool/Steel to Steel roller(choose one)
Counter Electronic, pneumatic
Program Control PLC(Delta/Siemens)
Speed Control Variable frequency speed regulating
Total Power 2.1kw
Power Supply 380v 50Hz
Net weight 1100kg
Dimensions 3600×1500×1800 mm
Embossing Heater (optional) Power: 1kw / 220V
Embossing Roller working temperature 60-80ºC

Good choice
1. We are a specialized in manufacturing Automatic Paper Making machine for 10 years.
2. We have a whole complete service, include researching, designing, manufacturing, selling and after-sale service. To keep the best product what you want.
3. Our factory located in Nanhai, Foshan city which near Guangzhou and HongKong. It's expedient to export for us.
4. 100% QC inspection and debugging before shippment.
5. 100% rest assured after-sales service.
Our service
Pre-sale service
Our professional sales team provide the professional consultation and best solution for actual situation and budget. Our professional researching-designing department can design the specific specification machine what you need
After-sale service
1. Warranty: 1 year quality assurance.
2.Our after-sale team have a rest assured global presence service even over the warranty period for you.
