HTC6180-1000mm Horizontal CNC Lathe Machine with Fanuc Controller
| US$10,500.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
GEEPRO
Guide Rail
Horizontal Guide Rail
Tool Holder
Single-tool Holder CNC Lathe
Power Source
Electric
Controlling Mode
Artificial
Automatic Grade
Manual
Setting Mode
Floor-type
Precision
Precision
Certification
CE, ISO 9001
Condition
New
Voltage
as Customer Request
After Service
Local or Engineers Available to Service Machinery
Guarantee
12months
Transport Package
Container
Specification
standard
Trademark
MEILI
Origin
China
HS Code
8458110090
Production Capacity
100-200PCS/Year
Product Description
Quick Delivery for Economical Fast Speed Flat Bed CNC Horizonal Lathe machine with SIEMENS808D/FUNUCTell us the size, material Details of your workpiece. And If there are some Workpiece drawing available ,it will be better. Our Technician team will receommend you the most economical and suitable machine Solutions in a short time.
The main performance characteristics: Widening high stability bed Two gear spindle speed,stepless in gear Wider layor board Intergrated automatic lubrication system Application: The machine is suitable to process all kinds of small and middle-sized shaft and plate workpiece,and could also turn various threads ,circle arc ,circle cone ,inside and outside surface of revolved body .This machine is widely used in sanitary ,value ,electrical appliance ,instrument ,automobile ,motor cycle ,bearing and so on.
Main Technical Specifications for Hot Sale Lathe machine.
| Specifications | Unit | HTC6140D |
| Max.swing over bed | mm | Ф400 |
| Max.swing over cross slide | mm | Ф210 |
| Distance between centers | mm | 750/1000 |
| X/Z axis travel | mm | X:260 Z:750/1000 |
| Spindle transmission type | Independent Spindle transmission ,in gear variable speed | |
| Spindle speed steep | variable | |
| Spindle speed | rpm | 100-3000 |
| Spindle nose | A2-5 | |
| Thru-hole dia.of spindle | mm | 56 |
| Spindle taper | MT6 | |
| Spindle motor | KW | 7.5 |
| Chuck size | mm | 250 |
| Ball screw dia.and pitch | mm | φ20X4/φ40X6 |
| X/Z axis feed motor torque | N.m | X:6 Z:10 |
| X/Z axis feed motor power | KW | X:1.5 Z:2.5 |
| X/Z axis fast moving speed | mm/min | X:4000 Z:5000 |
| X/Z axis Position accuracy | mm | 0.02/0.025 |
| X/Z axis repeatability | mm | 0.01/0.015 |
| Processing accuracy | IT6-IT7 | |
| Workpiece surface roughness | Ra1.6 | |
| Tailstock sleeve dia. | mm | 75 |
| Tailstock sleeve travel | mm | 140 |
| Tailstock sleeve taper | # | MT5 |
| Guide form | Spindle mountain+flat rail | |
| Total power capacity | KVA | 10 |
| Machine dimension(L×W×H) | mm | 2000X1050X1500 |
| G.W. | kg | 2000/2500 |
Other Model List of the Slat Bed CNC Lathe You can Select.
| Model | Remark | Swing dia.×Z travel -spindle bore(mm) |
| HTC0640 | LM guide | Φ300×200-Φ48.5 |
| HTC0620 | Closed guide | Φ200×200-Φ37 |
| HTC6125 | Closed guide | Φ250×300-Φ48 |
| HTC6130 | Wide guide | Φ300×350-Φ48 |
| HTC6132 | Wide guide | Φ320×450-Φ50 |
| H6135 | 6 class gear | Φ350/400×750/1m-Φ46 |
| H6136 | Spindle unit | Φ420×750-Φ58 |
| H6150A | 3 class gear | Φ520×1/1.5/2m-Φ82 |
| H6140C | Spindle unit | Φ420×750/1m-Φ66 |
| H6150B | 3 class gear | Φ510×1/1.5/2m-Φ82 |
| H6150C | Spindle unit | Φ510×1/1.5/2m-Φ86 |
| H6166C | Spindle unit | Φ660×1/1.5/2m-Φ112 |
| H6163 | 3 class gear | Φ630×1~6m-Φ100 |
| H6180 | 3 class gear | Φ800×1~6m-Φ10 |
