Monoblock ERP a+++ Heating Cooling and Hot Water Heat Pump with WiFi

Product Description

Monoblock Erp A+++ heating cooling and hot water Heat Pump with WiFi

Model				MGSDC-030IIC	MGSDC-050IIC	MGSDC-060IIC	MGSDC-080IIC	MGSDC-100IIC
HP				3HP	5HP	6HP	8HP	10HP
Ambient	Outlet	Power Supply		220-240V / 50-60Hz / 1ph or 380-415V / 50-60Hz / 3ph				380-415V / 50-60Hz / 3ph
+7°C	45°C	Heating Capacity	kW	9.65	16.45	19.90	24.90	30.90
		Power Input	kW	2.65	4.53	5.50	6.98	8.67
COP				3.64	3.63	3.62	3.57	3.56
-12°C	41°C	Heating Capacity	kW	6.85	11.44	13.50	16.52	20.61
		Power Input	kW	2.72	4.49	5.31	6.56	8.21
COP				2.52	2.55	2.54	2.52	2.51
-20°C	41°C	Heating Capacity	kW	5.79	9.55	11.80	14.52	17.45
		Power Input	kW	2.63	4.32	5.39	6.66	8.04
COP				2.20	2.21	2.19	2.18	2.17
-35°C	41°C	Heating Capacity	kW	3.42	5.68	7.39	8.80	10.92
		Power Input	kW	2.46	4.12	5.32	6.33	7.86
COP				1.39	1.38	1.39	1.39	1.39
+35°C	7°C	Cooling outlet	kW	7.62	13.18	16.21	20.51	23.80
		Power Input	kW	2.61	4.51	5.59	7.15	8.32
EER				2.92	2.92	2.90	2.87	2.86
Maximum Working Pressure			Bar	44 Bar
Compressor			-	Panasonic DC Inverter Compressor with EVI System
Refrigerant			-	R32
Fan Motor			-	Nidec DC Brushless Motor
Controller			-	Touchscreen LCD Controller with WIFI and 13 Languages
Water Heating Exchanger			-	Cooper Brazed Plate Heat Exchanger
External Cabinet			-	1.5MM Galvanized Steel With Powder Coating
EEV			-	Dunan
Outdoor Air Flow			m3 / h	2600	5600	5600	7800	7800
Water Flow (Built in Pump)			m3 / h	>1.6	>3.1	>3.1	>3.4	>3.4
Expansion Tank			L	2L
Water Pipe			inch	1"	1"	1"	1-1 / 4"	1-1 / 4"
Noise in 1M			dB(A)	≤50	≤56	≤57	≤59	≤60
Unit size			mm	925*375*770	1050*400*1350		1175*400*1482
Net Weight / Gross Weight			Kg	76 / 85	120 / 146	125 / 151	165 / 194	175 / 212
Remark			1.The values of heating(cooling) capacity/power input/COP(EER) are based on measurement of EN14511 standard.Usage environment, such as operation of the heat pump, room temperature and controller adjustments, may cause disparities between practically determined and these values; 2.Sound pressure level measured at distance of 1m from the device; 3.For wall-mounted type, the compressor is located in the outdoor unit;

Key parts of Mango all in one heat pump water heater DC inverter heat pump
Hydrophilic plus-size-area fins, ripple copper pipe...
Applicarion of Mango all in one heat pump water heater DC inverter heat pump

Good comments
FAQ : Marketing of Mango Energy.
Q1> What does mango energy company do ?
A1: Mango energy is professional manufacturer of ON/OFF heat pump , DC inverter heat pump, air source heat pump,water to water heat pump , swimming pool heat pump,high temperature heat pump so on all kind of heat pump.
Q2> What is the daily production of Mango energy company ?
A2: Mango energy one day produce heat pump water heater around 150~255 PCS / day.
Q3> What is Mango heat pump certification ?
A3 : Mango energy have : CE,CB, EN14511 certificate from TUV Lab,, got ISO9001. ISO18001, ISO14001 and CCC certificate. Get Class A+, A as ErP EN14825 test report .
Q4> Where are the Mango energy heat pump export to till now ?
A4 : Currently the products has been exported to Western Europe, North Europe, South Africa, Middle-East, South American and Australia market.
Q5> What is the marketing cooperation case with Mango energy ?
A5: Mango energy all find exclusive agent / distributor / wholesale / OEM
Mango energy is manufacturer , so we do not directly face to end user / retail ,
After sign sales contract at this district , we will do not sales to others buyers again,
So agent / distributor care for this district sales & service .
Q6> What Mango energy do for their agent / distributor /OEM ?
A6 : Mango energy offer sales training , heat pump & solar air conditioner product training,
After sales service training , maintenance machine training , big air chiller ,or heating
Project design case training , inside parts exchange training and test training.
Q7> How can get training from Mango energy ?
A7 : If have time , can visit to my factory to training, or invite we engineer team to yours side
Training , or by Video training online.
Q8> What Mango energy offer to their business partner ?
A8: Mango enrgy offer 1%~2% free spare parts according to order quantity .
Offer whole this district market exclusive sales right .
Offer rebate as this district agent sales amount within one year .
Offer best competitive price & repair parts .
Offer 24 hours online service .
Q9> where is Mango energy heat pump using ?
A9: Because Air source heat pump save energy around 70% , ( EVI heat pump and central cooling & heating heat pump ) is Widely used in home heating, hotels hot water & heating , restaurants, hospitals,schools, bath center, residential central heating and hot water plants, etc. Send your inquiry, right away!
