2400mm SMS Polypropylene Spunbond with Good Production Line

Product Description

2400mm SMS Polypropylene Spunbond with Good Production Line Quick Detail
Warranty:1 Years
Condition:New
Automatic Grade:Automatic
Place of Origin:Wenzhou,Zhejiang, China (Mainland)
Brand Name:YP(Yanpeng)
certificate:CE ISO
Certification:CE/ISO9001
Raw material:Polypropylene(PP)
Capacity:10-22 T/day
Application:Package-nonwoven shopping bag
Width:1600MM/2400MM/3200MM or as Customized
Color:As customer require
Product name:SMS Nonwoven Fabric Machine
Final products:Nonwoven Fabric
Name:1.6M/2.4M/3.2M SMS Nonwoven machine
After-sales Service Provided:Engineers available to service machinery overseas Product Description

Superior quality full automatic Three S nonwoven machine / SMS nonwoven machine for baby diaper.
This equipment uses polypropylene (PP) to produce nonwovens, and adopts negative pressure air-induced netting forming process, which makes PP spunbonded nonwovens have the characteristics of uniform coverage, high strength, good air permeability and good handle. It is widely used in medical treatment, protective articles, household, hotel accessories, cosmetic disposable goods, farm tools and garment packaging and architecture.
Our nonwoven machine has passed the certification of professional institutions and obtained professional certificates,such as CE and ISO9001.
Final product Category:SMS hydrophobic nonwoven
Soft and comfortable, no side effect on human body
High force, small variances between the vertical and horizontal force
Little elongation at break
Well uniformity
Well air-permeability
Well water-resistance
Production Application

Medical and Health: Opreation suit,cap, mask and so on. 2.Agricultural: Cover for plant to anti-frost, packing bags for crops etc.
3.Packing and Linning: Bag for shopping and gift paket, dust cover, sleeping bag gor children etc.
4.Hygiene: baby diaper, sanitary napkin and so on. Specification

Model No.	YP-SMS-1.6	YP-SMS-2.4	YP-SMS-3.2
SMS(Product width)	1600mm	2400mm	3200mm
Equipment Size	31*20*10m	32*21*10m	34*22*10m
Speed	400m/min	400m/min	400m/min
Gram Weight	12-150g/m2	12-150g/m2	12-150g/m2
Yield (according to 20g/m2)	10-11T/Days	15-16T/Days	20-22T/ Days

process flow:
Feeding→Extrusion Melting→filtering→metering→spinning→Cooling→Stretching
→Web spreading→Thermal bonding→slitting→collecting
Nonwoven machine is called nonwoven equipment or spunbonded nonwoven production line. Raw materials are blended, melted at high temperature, spinning, backlog, hot-pressed into cloth, winding and slitting into finished products. This is the main function and step of nonwovens production line. This machine includes feeding system, screw extrusion, filter, metering pump, spinning box, cooling system, drawing machine, etc.

Competitive Advantage:
1. The structure of the whole line is perfect and the operation is convenient.
2.The control elements are well made, with excellent performance and reliable technology.
3.The whole line is controlled by PLC and operated by touch screen.
4.The whole line is highly automated. Product Details

Place of Origin:	Wenzhou,Zhejiang
Brand Name:	YP(YanPeng)
Model Number:	YP-SMS 1600mm,2400mm,3200mm
Certification:	CE/ISO9001

Payment & Shipping Terms

Minimum Order Quantity:	1SET
Delivery Time:	150Days
Payment Terms:	T/T,L/C,D/P
Supply Ability:	50 sets per year
Port	FOB Ningbo

Principle Diagram

Our Service

Our Service:
1. We provide pre-sales, sales and after sales service, especially one year of free maintenance warranty.
2. If there are problems with the nonwoven machine parts, customer can take pictures and send to us by email to explain the situation, we will help to solve it on line or by email as soon as possible.
3. If there are big problems of the nonwoven machine caused by wrong operation, we will arrange professional engineer to solve the problem in customer's factory, but all the cost including visa, air fare and accommodations must be paid by customer.
Our company:
Zhejiang Yanpeng Non-woven Machinery Co.,Ltd is a professional non-woven production line manufacturer which engaged in development and production for many years.
We can provide customized single S, double S three S spunbond non-woven production line,SSMS, SMMS SMS spunmelt (spunbond & meltblown) production lines,and other PP,PET, BiCo spunbond production line to our customers.
Our company has already passed ISO9001:2010 international quality management system certification , standardization certification, CE certification, and we also have the right of import and export.
