High Guality Rubber Belt Cutting Machine

Product Description

Rubber Belt Cutting Machine
Name: Rubber Belt Cutting Machine
Model: FTJ1600 adjustable blades
Descriptions
Rubber Belt Cutting Machine is used for cutting various rubber sheets, rubber rolls.
The rubber slitting machine can be equipped with a feeding rack device to facilitate the placement of rubber rolls for cutting.
Technical parameters

Model	Min.Cutting width Adjustable	Working width	Cutting speed	Thickness of sheet	Motor power
FTJ1600	19mm	1600mm	8-10m/min	≤25mm	3.0 KW

Products pictures
Patterned rubber sheet sample is sent by customer,the thickness is 10mm, hardness 70 shore A,
Smooth cutting, straight edge:
Features
1.When Cutting different thickness of materials, Please rotate the right and left hand shanks top of the machine, thereby adjusting the upper and lower tool shaft clearance .
2.Rubber sheet can be fully cut through, also can not cut through, convenient winding roll.The adhesive strip can be torn off with a slight force of the hand.
3.The rubber slitting machine with feed roller, if the user's material surface is not smooth, it can prevent the bulging during the cutting process, ensure good cutting effect.
Quality control
We have quality inspectors on the production line.All products must be inspected before delivery.
1.All the raw materials were inspected as soon as they arrived at our factory.
2. Check all purchased parts and brands and all details during the production process.
3. Check all welding and installation details during the production process.
4. The quality and packaging of all products shall be subject to final inspection upon completion
