High Capacity Wood, Corn, Wheat, and Husk Hammer Mill
| US$2,200.00-15,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
JN650-1300
Cutter Material
Tungsten Carbide
Drive
Electric
Object
Wood, Wood
Type
Roller Crusher
Diameter of Rotor (mm)
650
Voltage
220V/380V/50Hz
Power
110
Weight (Kg)
3000
Color
Customers′ Requirement
Video Outgoing-Inspection
Provided
Principle
Roller Culling
Finished Surface
Outer Surface Process
Compressive Strength (For Crushing)
250-300MPA
Tongs′ Features
Adjustable Tongs
After-sales Service
Online Support, Field Installation
Warranty
1year
Transport Package
Contact Supplier to Negotiate Shipping Details
Specification
3000*1300*2600
Trademark
jinneng
Origin
Jinan, Shandong Provice, China
HS Code
8474209000
Production Capacity
500sets/ Month
Product Description
110kw JN65x1300 high-efficiency pulverizer1. JN65-1300 hammer mill, the motor and rotor of this machine installed on the same base.They are directly connected by coupling.The rotor has been passed dynamic balance test; it can rotate in both of forward backward direction. 2. There are symmetrical operation door and safety interlock in both sides. The operation doors are helpful to renewal the sieve plate and hammers, also helpful for checking up and debugging.Feed inlet is placed in the top of crusher which can be matched with all kind of feed equipment. MAINLY FEATURES: 1. The sieve holes are not easily clogged.
2. Smooth operation with low noise.
3. Simple structure and convenient maintenance.
4. Adopting a special mesh, it has high screening efficiency and long service life.
The hammer blade is made of high manganese alloy steel, with good wear resistance and extended service life.
The machine is composed of a feeding port, a feeding guide mechanism, an upper hell, a bearing seat, a rotor, an operating door, a base, a motor, etc.
MAINLY PARAMETERS:
| model | power (KW) | output T/H | draught fan(KW) | cyclone dust collector | fabric filter | air-lock valve | Number of hammer pieces | Overalldimension Length x width x height(mm) | screen size(mm) | weight(T) |
| 65-1000 | 90/110 | '3-4 | 18.5 | Φ1200 | 50 | 500x50 | 96 | 2600x1300x2600 | 2piece x988 x820 | 2.5t |
| 650-1300 | 110/132 | 5 | 22 | Φ1500 | 100 | 500x50 | 132 | 3000x1300x2600 | 2piece x1322 x820 | 3T |
| 1600-1000 | 160/185 | ,6-8 | 15 | Φ1200 | 50 | 600x60 | 144 | 2700x2300x2750 | 2piece x1600 x1400 | 4-4.5T |
