Xg 69m Hb69V Concrete Pump Truck Used Heavy Equipment
| US$185,000.00-400,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
HB69V
Machining Process
Piston Pumping
Structure
Cylinder Type
Productivity
180m³/H
Feeding Height
69000mm
Certification
ISO9001: 2000
Condition
Used
Color
White and Yellow
Front Outright Span
12.3 M
Outrigger Type
X Outriggers
Model
Mc13.54-61
Vehicle Weight
55000 Kg
Transport Package
Container
Specification
15760mm× 2550mm× 4000mm
Trademark
XG
Origin
China
HS Code
8705909990
Production Capacity
180m³ /H
Product Description
Product DescriptionBasic data:
The XG HB69V is a 69-meter truck-mounted concrete pump truck designed for efficient and reliable concrete placement in construction projects. It is known for its high efficiency, reliability, power, adaptability, smart control, smooth rotation, powerful swing, lightweight design, safe driving, rich configuration, user-friendliness, and easy maintenance.
| Outline dimension | mm | 16000×2500×4000 |
| Overall weight | kg | 46000 |
Key Features:
1. Efficient Pumping System: The HB69V offers more efficient pumping with a reliable system, stronger power, and improved adaptability.
2. Smart Control: Equipped with smart control systems for easier operation and maintenance.
3. Smooth Rotation and Powerful Swing: The pump truck features smooth rotation capabilities and a powerful swing function.
4. Lightweight Design: Designed with a lightweight structure for better fuel efficiency and maneuverability.
5. Safety and Rich Configuration: The HB69V prioritizes safety with a rich configuration of features to enhance the user experience. Detailed Photos
Product Parameters
| Overall | Outline dimension | mm | 16000×2500×4000 |
| Overall | Overall weight | kg | 46000 |
| Chassis | Model | - | Mercedes-Benz Actros |
| Chassis | Wheelbase | mm | 3200 + 1350 |
| Chassis | Max. speed | km/h | 85 |
| Chassis | Max. power | kW | 360 |
| Chassis | Emission standard | - | Euro VI |
| Pumping system | Theoretical output | m³/h | 180 |
| Pumping system | Concrete pumping pressure | MPa | 12 |
| Pumping system | Theoretical pumping times | Times/min | 22 - 24 |
| Pumping system | Delivery cylinder diameter × stroke | mm | φ260×2200 |
| Pumping system | Max. reach height | m | 68 |
| Pumping system | Boom type | - | 7RZ |
| Outrigger | Outrigger type | - | H type |
| Others | Control method | - | Manual/remote control |
| Others | Volume of water box | L | 1000 |
| Others | Intelligent technologies | - | Intelligent fabric, precise control of boom end trajectory, anti-rollover with full-range monitoring of outrigger expansion and contraction |
| Others | Energy-saving technology | - | Power self-adaptive energy-saving, reducing fuel consumption by 15% |
| Others | Structural design | - | Use of imported high-strength steel plate, veneer splicing process, passed German Duisburg welding quality system certification |
