Large-Scale Smelting Furnace with Environmentally Friendly Dust Removal System for Copper

Product Description

Main technical parameter			BM-110HV3-6WF			BM-110HV3-8WF
Spindle sleeve Specification			110*380 mm			110*380 mm
Range of spindle			Boring:1335r/min Tapping:556r/min Cutting:1335r/min			Boring:1335r/min ; Tapping:556r/min ; Cutting:1335r/min
Motor power			Cutting+boring:3kw*4p=3Pcs Tapping:2.2*6P=3Psc			Cutting+boring:3kw*4p=5Pcs Tapping:2.2*6p=3Psc
			Coolant:0.75kw*4p=1Psc Chip removal:0.2*4p=1psc			Coolant:0.8kw*4p=1Psc; Chip removal:1.18kw*4p=1psc
			Hydraulic pump motor:3.7kw*4p=1Psc			Hydraulic pump motor:3.7kw*4p=2Psc
Hydraulic oil specifications			Runliabao 46#F Antiwear hydraulic oil			Runliabao 46#F Antiwear hydraulic oil
Spindle shank Spcifications			BT-40			BT-40
Operating Voltage			3P-380VAC(50Hz)			3P-380VAC(50Hz)
Total Power			20.25kw			30.25kw
Overall dimension of Machine			2950*2300*2600			2950L*2500W*2600H
Machine weight			4000KG			6000KG

Provide one-stop turn-key solution, include but not limit to plant design, proposal, manufacturing, shipping, installation and commissioning services Long-term technical support, long-term machine warranty Over 20 years experience specialized in manufacturing melting& casting production line for brass copper and aluminum.
Our machines have been export to over 40 countries.
Italy technology adopted, the vertical rotary 8 stations 11 axis, boring, drilling, tapping, special tool processing special machine. HT300 bed are customized integral casting, three aging treatments to reduce the internal stress, to ensure no variant. All power unit holes and the reference surface are processed once by a 5 sides CNC machining center, so as to ensure the accuracy in installation and coordination. This machine adopts SND controller, feeding is executed by elevator and vibration plate, auto collect finished parts. High efficiency. Wide operation window is convenient for workpiece to enter and clamp exchange. Once workpiece clamping, 8 stations rotation, synchronous clamps 7 close 1 open, all function power units carry out the drilling,boring, tapping, special tool process in 3 directions synchronously according to customer drawings and processing standards. The blank pieces be completed in 1 clamp to save labor and time.
