16" Combined Machinery with 7 Functions (CF315/410-2000)

Product Description

Product Description
CF315 series is our new combination machine based on the above PM315/30T plus our different planer & thicknessors such as with C3-310 12" named CF315/310, with C3-410Q 16" named CF315/410 etc.
Product Parameters
PM315/30T series is the spindle moulder + panel saw with construction similar to our WS1000TA spindle moulder + MJ12-2000II panel saw, and it could be in different lenght sliding table from 1600mm to 2600mm.
CF315 series is our new combination machine based on the above PM315/30T plus our different planer & thicknessors such as with C3-310 12" named CF315/310, with C3-410Q 16" named CF315/410 etc.
01) Panel saw motor: 230V/400~, 50Hz 3000W
02) Spindle moulder motor: 230V/400~, 50Hz 2800W
03) Planer & Thicknessor motor: 230V/400~, 50Hz 3000W
04) Packing size: 2300x1610x1105mm with 2M sliding table
16"PLANNER AND THICKNESSER:
1) Motor: 3000W
2) Planning table size: 410x1600mm
3) Thicknessing table size: 410x750mm
4) Cutter block diameter: 95mm
5) Feeding block diameter: 40mm
6) Cutting knife (psc): 4
7) Fence tilt: 0~45
8) Max cutting depth: 5mm
9) Max thicknessing heigh: 220mm
10)Cutting block speed-50hz: 4100
11)Cutting block speed-60hz: 4800
12)Feeding speed-50HZ: 6m/min
13)Feeding speed-60HZ: 7.2m/min
SAW
1) Main blade size: 315x30x3mm
2) Main blade speed: 4500r/min
3) Scoring blade size: 90x20x3mm
4) Scoring blade speed: 8500r/min
5) Max cut depth 90° : 100mm
6) Max cut depth 45° : 80mm
7) Major table size: 1650X380mm
8) Sliding panel size: 270x2000mm
9) Cross cut table size: 880x580mm
10)Cross cut fence: 1200~2200mm
11)Max cutting width: 720mm
12)Max cutting length: 2000mm
SPINDLE MOULDER:
1) Spindle shaft diameter: 30mm
2) Spindle travel: 100mm
3) spindle speed: 1800rpm/3000rpm/6000rpm/9000rpm
4) Table size: 1650X380mm
5) Max tool diameter: 200mm
6) Fence tilt: 45° -90°
7) Vacuum port diameter: 100mm
PACKING SIZE: 1860X1610X1120mm; 2060X320X250mm
N/G WEIGHT: 700/870kgs

SPECIFICATION:

16"PLANNER AND THICKNESSER:

1) Motor: 3000W

2) Planning table size: 410x1600mm

3) Thicknessing table size: 410x750mm

4) Cutter block diameter: 95mm

5) Feeding block diameter: 40mm

6) Cutting knife (psc): 4

7) Fence tilt: 0~45

8) Max cutting depth: 5mm

9) Max thicknessing heigh: 220mm

10)Cutting block speed-50hz: 4100

11)Cutting block speed-60hz: 4800

12)Feeding speed-50HZ: 6m/min

13)Feeding speed-60HZ: 7.2m/min

SAW

1) Main blade size: 315x30x3mm

2) Main blade speed: 4500r/min

3) Scoring blade size: 90x20x3mm

4) Scoring blade speed: 8500r/min

5) Max cut depth 90° : 100mm

6) Max cut depth 45° : 80mm

7) Major table size: 1650X380mm

8) Sliding panel size: 270x2000mm

9) Cross cut table size: 880x580mm

10)Cross cut fence: 1200~2200mm

11)Max cutting width: 720mm

12)Max cutting length: 2000mm

SPINDLE MOULDER:

1) Spindle shaft diameter: 30mm

2) Spindle travel: 100mm

3) spindle speed: 1800rpm/3000rpm/6000rpm/9000rpm

4) Table size: 1650X380mm

5) Max tool diameter: 200mm

6) Fence tilt: 45° -90°

7) Vacuum port diameter: 100mm

PACKING SIZE: 1860X1610X1120mm; 2060X320X250mm

N/G WEIGHT: 700/870kgs

Detailed Photos
