High Quality HD Ahd Tvi Cvi Analog IP Hybrid Mobile Standalone Car Bus Truck Vehicle Managed DVR Video Recorder

High Quality HD Ahd Tvi Cvi Analog IP Hybrid Mobile Standalone Car Bus Truck Vehicle Managed DVR Video Recorder

US$99.00-102.00 5 Pieces (MOQ)

Basic Info.

Model NO.
HC-XVR5MP2H16
Compressed Format
H.265
Operating System
Linux
Application
Commercial DVR
Interface Type
BNC/VGA/HDMI
Video Input/Output
16 Channel
Audio Input/Output
8 Channel
Remote Control
With Remote Control
SATA
8tb X 2
Hybrid Mode
Ahd+Tvi+Cvi+CVBS+IP
Utc
Coaxial Control
PTZ
Yes
Alarm
4 Channel
Resolution
5MP
WiFi/3G/4G
Support
Transport Package
Neutral Packing
Specification
380*295*55 mm
Trademark
HICOTEK/OEM/ODM
Origin
China
HS Code
8525909090
Production Capacity
5000PCS/Month

Product Description

Features:
16CH 5MP (TVI/AHD/CVI/CVBS/IP) Hybrid DVR
Video Preview: 16CH Mixed 5MP Cameras Input
Video Output: 1x HDMI,1x VGA,1x CVBS
HDD: 2 SATA, MAX 6TB Each
Model NO. HC-XVR5MP2H16
XVR System
Type 16CH 5MP Hybrid DVR
Compression Method H.265/H.264
Main Processor 3531D_4*2828_12G
Operating System Embedded LINUX
HDD 2 SATA, MAX 6TB Each
Display & Recording
Video Input 16CH
Encode Capacity 1.AHD/TVI:16CH 5M@6fps recording
2. HVR:12CH 5M@6fps Analog + 4CH 5M@25fps IP recording
3.HVR:8CH 5M@10fps Analog + 8CH 5M@25fps IP recording
4.HVR:4CH 5M@10fps Analog + 12CH 5M@25fps IP recording
5.NVR:16CH 5M@25fps IP recording
Search Mode Time, Date, Alarm, Motion Detection, Exact Search
Playback Mode Normal Play, Fast Forward, Fast Rewind,
Frame by Frame, Zoom In /Out
Playback & Backup
Decode Capability MAX 4CH 5MP
Sync Playback 1.AHD/TVI: 4CH 5M@6fps playback
2. HVR: 4CH 5M@25fps playback
3.HVR: 4CH 5M@25fps playback
4.HVR: 4CH 5M@25fps playback
5.NVR: 4CH 5M@25fps playback
Search Mode ALL, Channel, Manual, Time, Date, Motion Detection
Playback Functions Play, Pause, Stop, Fast play, Rewind
Backup Mode USB Device/DVD/CD/Network
Video | Alarm | Audio
Video Output 1x HDMI,1x VGA,1x CVBS
Audio 8CH
Alarm 4CH
Network
Interface RJ45 Port / 10M / 100M Adaptive
IP Address ; TCP/IP, DHCP, UDP, SMTP, NTP
CMS Software Support
Cloud Support iCloud Software one‐click online; Support IE Firefox
Google Chrome Mac OS Safari
Language 28 kinds of Languages
Smart Phone Iphone, Ipad, Android, Android Pad
General
Voltage DC 12V
USB Port 2 USB2.0
PTZ Pelco-D, Pelco-P
RS485 YES
Size 380*295*55 mm
Weight 5.0 Kgs (Without HDD)
