Basic Info.
Needle Bar Style
Single Bar
Computerized
Computerized
Certification
CE, ISO9001: 2000
After-sales Service
1year
Warp Knitting Machine
Weft Insertion
Knitting Machine
Backlit and Banner
Backlit
Warp Knitting Machine
Banner
Warp Knitting Machine
Transport Package
Wooden Pallet
Specification
Pattern disc or EL
Production Capacity
15sets/Week
Product Description
The base fabric of the warp knitted light box fabric is woven on a double-axis Warp Knitting Machine, mainly RS2(3) MSU S/EMS type Raschel type Warp knitting machine and Copcent ra HS2ΟST type Trico warp knitting machine two. In practice, the RS2MSU S warp knitting machine can be used for knitting, the general choice of machine numbers E12 to 24, mostly with E18.
The warp knitted fabric is processed by the double-axis warp knitting machine, due to good mechanical properties, simple process, short process, fast and low cost, etc., as a flexible light box base cloth material has been used in large quantities. China's current production of warp knitting light box fabric is quite large. Warp-knitted bi-axial light box fabric belongs to the fiber-reinforced composite material, the base fabric is generally bi-axial warp-knitted fabric, the substrate is mostly polyvinyl chloride (PVC) resin material, its main production process is raw materials - warping - weaving - finishing (calendaring lamination or coating). model RS2MSU S; E18; the number of combs used 2; width 541 cm (213"); machine speed: 1000 r/min.
In this process, the warp lining comb FB3 does not move laterally, but only smoothly places the warp yarn pad between the needles, while the ground comb uses a handful of warp flat pads to bind the warp lining yarn layer and the weft lining yarn layer.
