Haitai-7140 Factory Price 3.5 Ton Mini Excavators

Haitai-7140 Factory Price 3.5 Ton Mini Excavators

US$8,999.00-29,999.00 1 tower (MOQ)

Basic Info.

Model NO.
HT-ZS-7140
Type
Crawler Excavator
Usage
GM Excavator
Bucket
Backhoe
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Bucket Capacity
0.5~1.0m³
Size
Small-Scale
Certification
ISO9001: 2000
Condition
New
Model
Ht25y
Operating Weight
2510kg
Maximum Excavation Height
3980mm
Maximum Discharge Height
2660mm
Maximum Digging Depth
2510mm
Maximum Digging Radius
4236mm
Rotation Speed
9.5 Minutes Per Revolution
Engine Model
Yangma 3tnv76-P
Fuel Tank
28L
Transport Package
Wooden Case
Specification
3850*2280*1300/1500Telescoping
Trademark
Haitai
Origin
China
HS Code
8429521200
Production Capacity
3000 Units Per Year

Product Description

product details

Mini Crawler Hydraulic Excavator Tractor Backhoe Excavator Price for Sale
Haitai excavator supports multifunctional operation, quick connection of accessories, excavation, crushing, ditch cleaning, drilling and soil pushing
Excavator features

A compact excavator can easily pass through narrow passages and doors.
2. The excavator's retractable chassis system and bulldozer allow for configuration of the excavator to achieve excellent performance
Work stability and optimal performance.
3. Adopting imported engines and perfectly matched hydraulic systems to provide efficient, economical, and reliable support for the most challenging work of excavators
Performance.
4. The bucket hose is well protected in the boom, and the excavator oil cylinder is installed above the structure.
5. The operating area is spacious, with a comfortable layout and convenient operation.
6. Excellent engines provide excellent power with minimal fuel consumption, thereby improving the productivity of each fuel tank.
Product parameters
Model HT25S Engine model Yangma 3TNV76-P
bucket capacity 0.075m³ engine form water-cooled inline three cylinder diesel engine
operating weight 2510mm rated power 20.6PS(15KW)/2200rpm
overall length 3850mm climbing ability 30°
overall height 2280mm maximum shaking digging force 22.8KN
overall width Shrink 1300, extend 1500mm hydraulic system pressure 22.5mpa
maximum excavation height 3980mm ground specific pressure 32kpa
maximum unloading height 2660mm vertical elevator 800kg
maximum excavation depth 2510mm horizontal lifting force 520kg
maximum excavation radius 4236mm track width 250mm
minimum front rotation radius 1850mm(1400mm) track length 1860mm
minimum rear rotation radius 710mm driving speed (low speed, high speed) 2.6km/h 4.5km/h
and rotation speed 9.5 rpm fuel tank capacity 28L

Product Features

The characteristics of tracked small excavators:
1. High fuel efficiency and strong power. Low fuel consumption, high configuration, and superior performance.
2. The standard bulldozer can level the site, backfill the soil, and increase stability
Mechanical;
3. Easy to operate, compact and flexible, with convenient transportation, it can be operated in narrow areas, especially
Suitable for orchards such as kiwifruit, vineyards, oranges, navel oranges, trenching, fertilization, weeding, etc.;
4. Arm side moving device: The front of the body is equipped with an arm side moving device. Arms can swing
90 degrees on the left and 50 degrees on the right, truly achieving similar direct excavation work
Reaching the wall root area without frequent physical movement. More suitable for small-scale on-site operations.
Product display

Company strength

1) How old is your factory? We have 20 years of production and nearly 10 years of experience, and we export to over 120 countries and regions. 2) What payment method can you accept? Usually, both T/T and L/C are visible to us. 3) What is the delivery time? Received 7% wire transfer or letter of credit What is your warranty for the next 40 to 30 working days? Usually it takes one year, and if there is a large quantity, we can negotiate. 5) What is your minimum order quantity? Minimum order quantity: 1 set 6) Can you accept OEM services? Yes, my friend. 7) Optional attachments? Remote control, basket, auger, grab, top seat, rear legs
