9500lb Winch with Synthetic Rope Waterproof 4X4 Offroad
Basic Info.
Model NO.
9500LB
Type
Electric Winch
Power Type
Series Motor DC
Pull Direction
Forward
Electric Winch Model
4WD Winch
Working Voltage of Electric Winch
Low Voltage
Brand
Chima
Applicable Environment
Mountain Road&Swamp
Certification
TUV, GS, CE, MD
Color: Grey
Wireless Remote Control: Optional
Rope: Steel Wire Rope
Synthetic Rope: Optional
Transport Package
Export Carton Box or Color Box
Specification
CE, MD approved
Trademark
CHIMA
Origin
Ningbo, China
HS Code
84253190
Production Capacity
12, 000PCS/Month
Product Description
Self recovery professional electric winch, best choice for off-road enthusiast!| NINGBO CHIMA WINCH CO., LTD. | |||
| No. 38 DONGBEI RD, DONGQIAO TOWN, YINZHOU DISTRICT, NINGBO, 315157 ZHEJIANG,CHINA | |||
| 4WD WINCH QUOTATION | |||
| Customer: | |||
| Supplier: NINGBO CHIMA WINCH CO., LTD | |||
| FROM | Zhejiang Province, China | TO | |
| TERMS OF PAYMENT | TT or L/C | PACKING | EXPORT CARTON |
| TIME OF SHIPMENT | FOB NINGBO | ||
| Product info. | Points | Picture | |
| Model | 9500lbs | ||
| Unit Price(USD) | |||
| Performance | 12VDC / 24VDC | ||
| Single line rated pull | 9500lb(4318kgs) | ||
| Motor | 6hp/4.5kw,Series Wound | ||
| Control | Remote switch,11.5ft(3.5m)lead | ||
| Gear train | 3 Stage Planetary | ||
| Gear reduction ratio | 265.2:1 | ||
| Braking Action | Automatic In-The-Drum | ||
| Drum size | Diameter2.5"(63.5mm) Length 8.8"(224mm) | ||
| Cable | 9.5mm*26m | ||
| Fairlead | 4-Way Roller Fairlead | ||
| Wireless Remote Control | Included | ||
| Battery | Recommended:650CCA minimum for winching | ||
| Battery Leads | 2 gauge,72"(1.83m) | ||
| Finish | Black/Dark Grey | ||
| Weight | N.W.88lbs(42kg) G.W.95lbs(46kg) | ||
| Overall dimentions | (LxWxH)20.9"x6.3"x8.35"(530x160x212mm) | ||
| Mounting Bolt Pattern | 10.00±0.015"x4.50±0.010"(254x114.3mm) | ||
