China Lathe Machine for Sale Horizontal Lathe Machine (CD6241)

Product Description

Product Description
Spindle Bore 52mm metal turning Lathe (CD6241)
CAPACITY
Swing over bed 410mm(16")
Swing over cross slide 255mm(10")
Swing in gap 580(23")
Length of gap 250(10")
Distance between centers 1000mm(40")
Center height 20.5"
Width of bed 250(10")


Product Parameters

Spindle bore 52mm lathe machine (CD6241)
Model	CD6241× 1000	CD6241× 1500
Max.swing over bed	Φ410mm(16")
Max.swing over cross slide	Φ255mm(10")
Max. swing over gap	Φ580mm(23")
Center height	205mm(8")
Distance between centers	1000mm(40")/1500mm(60")
Width of bed	250mm(10")
Max.section of tool	20mm×20mm(3/4"×3/4")
Max.travel of cross slide	210mm(8 1/2")
Max.travel of compound rese	140mm(5 1/2")
Spindle bore	Φ52mm(2")
Spindle nose	D1-6
Taper of spindle speed	M.T.#6
Range of spindle speed	16changes25-1800r/min
Leadscrew pitch	4 T.P.I.
Range of metric longitudinal feeds range	0.05-1.7mm/rev(17 Nos)
Range of inch longitudinal feeds	0.002"-0.067"/rev (17 Nos)
Range of metric cross feeds	0.025-0.85mm/rev (17 Nos)
Range of inch cross feeds	0.001"-0.0335"/rev (17 Nos)
Range of metric threads	0.2-14mm(NO. 39)
Range of inch threads	2-72 T.P.I.(NO. 45)
Range of Diametrical pitch	8-44D.P.(21Nos)
Range of module pitches	0.3-3.5 M.P.(18Nos)
Dia. of tailstock sleeve	50mm(2")
Travel of tailstock sleeve	120mm(4 3/4")
Morse taper of tailstock sleeve	M.T.#4
Power of main motor	2.2/3.3kw(optional 3/5.5kw)
Power of coolant pump	4P,3PH 90W
Overall diamension(L*W*H)	1940mm×850mm×1320mm
Packing size(L*W*H)	2070mm×940mm×1600mm
N.W/G.W	1550kg/1760kg

Standard accessory:

3 jaw chuck 200MM ,4 jaw chuck 250MM

change gears set

chasing dial indicator

reduction sleeve, dead centers

full length splash guard

coolant system, brake system

face plate, steady rest, follow rest

work light, tool box&tools

Optional accessory:
Tool post cover
Taper turning attachment
2 axis DRO Lathe tools -20X20MM/9pcs
Quick change tool post
Live center
CE

Detailed Photos
DIMENSION AND WEIGHT Overall dimension(L× W× H) mm 1940× 850× 1300 1940× 850× 1320 Packing size(L× W× H)mm 2060× 900× 1640 2060× 900× 1640 Net weight/Gross weight 1500/1750 1550/1800
The specification of bench lathe (CD6241)HEADSTOCK Spindle nose D1-6 Spindle bore 52mm(2") Taper of spindle bore No. 6Morse Range of spindle speed 16 changes 45-1800r/min

FEEDS AND THREADS Max. Travel of compound rest 102mm(4") Max. Travel of cross slide 210mm(8-1/4") Leadscrew pitch 4T. P. I. Max. Section of tool 20× 20mm(13/16") Longitudinal feeds range 0.05-1.7mm/rev(0.002"-0.067"/rev) Cross oeeds range 0.025-0.85mm(0.001"-0.0335"/rev) Metric threads range 39kinds 0.2-14mm Inch threads range 45kinds 2-72T. P. I Diametrical pitchesrange 21kinds 44D. P. Module pitches range 18kinds 0.3-3.5M. P.
TAILSTOCK Dia. Of tailstock sleeve 50mm(2") Travel of tailstock sleeve 120mm(4-3/4") Morse taper of tailstock sleeve No. 4 Morse Cross adjustock ± 13mm(± 1/2")
Packaging & Shipping

PACKING SIZE:Full wooden case for sea
CM6241/1000:2060x9000x1640mm ,1160/1350KG
Payment:Bank TT
30% down oayment is enough,70% balance befor Bill of lading
