18/30/36kv NFC 33 226 3X240mm2 Aluminum Three Core XLPE/PVC Insulated PVC Sheathed Cis Cable Hta Torsade Cable Medium Voltage Electric Power Cable

18/30/36kv NFC 33 226 3X240mm2 Aluminum Three Core XLPE/PVC Insulated PVC Sheathed Cis Cable Hta Torsade Cable Medium Voltage Electric Power Cable

US$0.10-10.00 1,000 Meters (MOQ)

Basic Info.

Model NO.
3x240 NFC 33 226
Current
DC & AC
Insulation Material
PVC
Sheath Material
PE
Material Shape
Round Wire
Wire Core Material
Aluminum Conductor
Certification
ISO, CCC
Brand
Yifang
Rated Voltage
18/30kv
Conductor
Copper
Insulation Screen
with Powder Over It
Sheath
PE
Sheath Color
Black
Cores
Three Bundles
Section Area
150mm2
Country Exported
West Africa:Togo,Cote Diva,etc
Other Sizes
3X150mm2
Other Voltage
12/20kv
Transport Package
Wooden Drum or Wooden Steel Drum
Specification
1.1m drum or 2.2drum
Trademark
Yifang Cable
Origin
China
HS Code
8544601200
Production Capacity
1000km Per Month

Product Description

Câble HTA Torsadé Souterrain 18/30/36KV NFC 33 226 3×240 mm² Alu Câble HN33S26
Product Description
DESCRIPTION
Utilisation
Le câble MT NFC 33-226 est destiné à la distribution publique moyenne tension HTA 12/20 kV.
Il peut être constitué de 1 ou 3 conducteurs de phase.
L'étanchéité longitudinale est assurée par une poudre gonflante.
La technologie de sa fabrication permet de le poser sans protection mécanique
supplémentaire.
Norme : NF C 33 226, IEC 60502-2
Product Parameters
N0 Fiches Techniques Unités Données Spécifiques Données du fabricant
1 Fabricant A indiquer YIFANG ELECTRIC GROUP INC.
2 Norme CEI ou équiv. IEC60502-2, NFC 33226
3 Conducteur Alu Alu
4 Isolation PR PR(XLPE)
5 Souplesse Classe 2 Classe 2
6 Tension maximale kV 36 kV 36 kV
7 Fréquence nominale 50 Hz 50 Hz
8 Section mm2 1x3x240 1x3x240
9 Intensité régime permanent enterré à 20°C A 398 398
10 Température max. âme °C 70 90
11 Masse approximative Kg/km 5539 5539
12 Chute de tension à cos phi = 0,8 V/A/km 0,33 0,33
13 Marquage 18/30 à 36 kV C33 226 18/30 à 36 kV C33 226
1x3x240 mm² Alu 1x3x240 mm² Alu
marquage métrique, la norme et marquage métrique, la norme et
CEET sur chaque conducteur à chaque 2 mètres. CEET sur chaque conducteur à chaque 2 mètres.
14 Couleur Noir Noir
Detailed Photos
Company Profile Yifang Electric Group Inc. mainly specialized in wires&cables, including designment, production and sale.
Products are mainly covering low,medium,high voltage(1KV to 220KV) XLPE Insulated power cable,PVC insulated power cable,ABC cable,building cable control cable,rubber cable welding cable Etc.
Our XLPE cable can be manufactured according to the company's specification which is equivalent to IEC 60502,IEC60332,IEC60754. Some indexes are superior to above international standard.
Certifications
FAQ 1.Q:Are you a factory or trading company?
A: Manufacturing base in Henan ,China, with more than 500 workers.
2.Q:How can I visit there?
A: Sure,If you need,we will arrange the driver to pick you up.
3.Q:How can I get some samples?
A: Contact me on below,Determin sample and address for shipping.
4.Q:Have you ever supplied cables to our country?
A: Yifang Cables have been sold to over 100 countries and regions in the world. can you contact me for details.
5.Q:What is your MOQ?
A: MOQ Normally 500 meters for big diameter cables.Please contact me for detail info if you have specific cable requirement.
6. Q:When can I get the price?
A: Usually quote within 6 hours after we get your inquiry.
7.Q:How long is your delivery time?
A: According to your order's quantity.Usually our lead time is 3 - 20 working days.
