Whisky Distiller Moonshine Still Pot Copper Commercial Distilling Equipment

Whisky Distiller Moonshine Still Pot Copper Commercial Distilling Equipment

US$3,000.00-20,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
ZL
Producing Method
Distill
Main Ingredient
Wheat ,Barly etc
Taste
Customized
Packaging
Customized
Applicable Industries
From The Wheat ,Barly etc Fermented Wort Solution
Core Components
Condenser,Gin Basket,Dephlegmator,Reflux Colum,
Funtion
Distill The Alcohol From The Wheat
Feeding
Herbal/Flower/Stem/Seed/Fruit+ Water (Solvent)
Heating Model
Steam/Hot Oil/Hot Water/Electrical
Output
Liquid Solution
Tank Layer
Single Layer/Double Jacketed
Control
Fully Automatic
OEM
Parameter Customization
Material
304/316L Stainless Steel/Copper
Related Words
Moonshine Still/Copper Still/Commercial Distilling
Key Selling Points
Commercial Distilling Equipment
Transport Package
Wooden Case Packaging/According to Customer
Specification
20L-10000L
Trademark
JOSTON
Origin
Wenzhou, China
HS Code
843840000
Production Capacity
30 Sets/Month

Product Description


wiskey distiller machineis distill the alcohol from the wheat ,barly etc fermented wort solution which can get high degree pure wiskey liquor .
alcohol solution is first preheated through the pipeline in the distiller, which also has the effect of enhancing reflux. The heated solution then enters the top of the separator and runs down the distiller to meet the rising steam. Volatile substances arrive at the Distiller in the form of steam, and liquid waste flows out from the bottom of the separator.
In the distillation column, the continuous occurrence of reflux and distillation process means that the liquid composition on each distillation plate is consistent. As a result, the distiller always knows where to collect the fusels (near the bottom of the distillation equipment), what the alcohol concentration is above each layer, and where to collect the methanol. This equilibrium system can be maintained as long as the temperature gradient can be maintained, and the amount of substances flowing out of the distillation equipment is equal to the amount of alcohol solution continuously added. In this way, the distiller can obtain the parts of head, heart and tail at the same time. The head can be discharged in the form of liquid, or in the form of gas at the top of the distiller, and then be condensed and collected. The core can be discharged from any distillation plate, depending on the alcohol concentration and style of the product; fusels are also discharged. After the head and tail will continue to the next process to get the remaining alcohol. Finally, it should be noted that if there is liquid accumulation at the bottom of the distiller, they will be recovered to the top of the separator. This step, in fact, can be imagined that if the separator and the distiller are a large tower, then it is the next layer of the situation that will happen.
the equipments including still pot ,helmet ,condenser etc pipeline system .
Technology data specification:
Type Volumn Compenent
Wisky Distiller 50-5000L Still pot,helmet,Column,Dephlegmator,Condenser,Pipe system

Function for the component of the equipment:
Item Material Function Type
still pot SS304 ,SS316Land red copper Material/mash distilling Tank/pot
Helmet SS304 ,SS316L and Full red copper Improve high quality Ellipse/round type
Gin basket glass / red copper Flavour spirits, making Gin Basket, glass
Distilling column 16 plate SS304 ,SS316L and Full red copper Distilling alcohol Column
Dephlegmator SS304 and SS316L Partial condenser Column
Condenser SS304 Condensing to alcohol Column

Packaging Details
Under normal circumstances, we will use PE wrapping film for part of the product, then use wooden case packaging, or according to the special requirements of the customer packaging;If exported to European countries, we will fumigate the wooden cases.
Shipping Details
Under normal circumstances, we will use trucks to transport products to Qingdao port;Or according to customer requirements, choose the most convenient, the most economic mode of transportation.
FAQ
Q :What about your factory?
A :Our factory is located in Wenzhou city ,Zhejiang Province and have more than 15 years experience on machinery making.
Q :How long the warranty will be?
A :We provide 1 years warranty for the machine running ,but we will afford whole -life service for the machine .
Q :Which kind payment do your company do now ?
A :We accept Western Union, T/T ,D/P,D/C and irrevocable L/C payable etc.
Q :Do you supply installation equipment in oversea?
A :Yes, if need, we can send our engineer to your plant to help you do installation and commission.
Q :How can we know the order production status ?
A :We will arrange the person to take photo or video during manufacturing in every week to make you to know the production status.When goods are finished,we will take detailed photos or video for your checking ,after approve ,then we will arrange shipment .also you can arrange FAT in our plant when the goods is ready here.
Q :how about your company after-sale serivce ?
A :1. We provide long-term after-sale service.
2. we can do installation and commission for the equipment in your plant if necessary .
3. Meanwhile, you can call or e-mail us to consult on any relevant question since we have a special line for after-sale service. Alternatively, you can communicate on-line with us to solve any problem.
