Basic Info.
Tool Handle Type
Triangle Handle
Type
Bimetallic Hole Opener
Shank Diameter (Inches)
M9.5
Production Capacity
1000/Week
Product Description
Product Parameters
model | diameter | Maximum cutting depth | Shank diameter | Number of teeth | full length |
( mm ) | ( mm ) | ( inch ) | ( TPI ) | ( mm ) |
16MM | 16 | 25 | M9.5 | 4-6 | 83 |
18MM | 18 | 25 | M9.5 | 4-6 | 83 |
19MM | 19 | 25 | M9.5 | 4-6 | 83 |
20MM | 20 | 25 | M9.5 | 4-6 | 83 |
22MM | 22 | 25 | M9.5 | 4-6 | 83 |
25MM | 25 | 25 | M9.5 | 3-4 | 83 |
28MM | 28 | 25 | M9.5 | 3-4 | 83 |
30MM | 30 | 25 | M9.5 | 3-4 | 83 |
32MM | 32 | 25 | M9.5 | 3-4 | 83 |
35MM | 35 | 25 | M9.5 | 3-4 | 83 |
38MM | 38 | 25 | M9.5 | 3-4 | 83 |
40MM | 40 | 25 | M9.5 | 3-4 | 83 |
42MM | 42 | 25 | M9.5 | 3-4 | 83 |
45MM | 45 | 25 | M9.5 | 3-4 | 83 |
48MM | 48 | 25 | M9.5 | 3-4 | 83 |
50MM | 50 | 25 | M9.5 | 3-4 | 83 |
51MM[2inch] | 51 | 25 | M9.5 | 3-4 | 83 |
53MM | 53 | 25 | M9.5 | 3-4 | 83 |
55MM | 55 | 25 | M9.5 | 3-4 | 83 |
60MM | 60 | 30 | M9.5 | 3-4 | 100 |
65MM | 65 | 30 | M9.5 | 3-4 | 100 |
68MM[2-11/16inch] | 68 | 30 | M9.5 | 3-4 | 100 |
70MM | 70 | 30 | M9.5 | 3-4 | 100 |
75MM | 75 | 30 | M9.5 | 3-4 | 100 |
76MM[3inch] | 76 | 30 | M9.5 | 3-4 | 100 |
80MM | 80 | 30 | M9.5 | 3-4 | 100 |
85MM | 85 | 30 | M9.5 | 3-4 | 100 |
90MM | 90 | 30 | M9.5 | 3-4 | 100 |
95MM | 95 | 30 | M9.5 | 3-4 | 100 |
100MM | 100 | 30 | M9.5 | 3-4 | 100 |
102MM[4inch] | 102 | 30 | M9.5 | 3-4 | 100 |
105MM | 105 | 30 | M9.5 | 3-4 | 100 |
110MM | 110 | 30 | M9.5 | 3-4 | 100 |
115MM | 115 | 30 | M9.5 | 3-4 | 100 |
120MM | 120 | 30 | M9.5 | 3-4 | 100 |
125MM | 125 | 30 | M9.5 | 3-4 | 100 |
130MM | 130 | 30 | M9.5 | 3-4 | 100 |
135MM | 135 | 30 | M9.5 | 3-4 | 100 |
140MM | 140 | 30 | M9.5 | 3-4 | 100 |
145MM | 145 | 30 | M9.5 | 3-4 | 100 |
150MM | 150 | 30 | M9.5 | 3-4 | 100 |
152MM[6inch] | 152 | 30 | M9.5 | 3-4 | 100 |
155MM | 155 | 30 | M9.5 | 3-4 | 100 |
160MM | 160 | 30 | M9.5 | 3-4 | 100 |
165MM | 165 | 30 | M9.5 | 3-4 | 100 |
170MM | 170 | 30 | M9.5 | 3-4 | 100 |
175MM | 175 | 30 | M9.5 | 3-4 | 100 |
180MM | 180 | 30 | M9.5 | 3-4 | 100 |
185MM | 185 | 30 | M9.5 | 3-4 | 100 |
190MM | 190 | 30 | M9.5 | 3-4 | 100 |
195MM | 195 | 30 | M9.5 | 3-4 | 100 |
200MM | 200 | 30 | M9.5 | 3-4 | 100 |
Detailed Photos
