Auto Feeding Gravity Metal Detector Separator for Crusher Recycled Material Regenerates Granulated Plastic Raw Material
| US$2,100.00-2,700.00 | 1 pc (MOQ) |
Basic Info.
Certification
CE
Condition
New
Customized
Customized
Alarm Form
Sound and Light Alarm
Capacity
800kg/Hr
Usage
Mestal Detecting Separators
Function
Automatic Operation
Working Temerature Range
-10 to +80degrees
Voltage
1pH220V60Hz
Cutting Seep
Free Fall
The Compressed Air
4bar - 8bar
Blanking Diameter
80mm
Precision
0.2-0.3mm
Discharging Time
0.1-15min
Transport Package
Wood
Specification
810*370*310mm
Trademark
Sanzhong
Origin
Guangdong
HS Code
84778000
Production Capacity
2000PC\Year
Product Description
Mchinery Principle: The raw materials travel from the repository or feeding system through the metal detector. If no metal is detected, the raw materials will pass through the metal detector module and into the storage bins. However, if metal is detected from the raw materials, the points of material valve will begin to operate and separate out the metal and trace amounts of the raw materials. The speed of the separation output can be adjusted according to production needs and metallic particles as small as 0.4mm can be detected and isolated.
Feature:
| 1.Intelligent detection, maintenance-free. |
| 2.The contacting parts is made of 304 stainless steel. |
| 3.Special structure design can effectively avoid vibration,effect of external factors such as interference noise and products. |
| 4. A variety of caliber optional, Model meets all of the actual application. |
| 5Can avoid product accumulation, Obstruction caused by the mould. |
| Model id | RL-25G | RL-30G | RL-50G | RL-80G |
| Voltage | 220V,50/60Hz | 220V,50/60Hz | 220V,50/60Hz | 220V,50/60Hz |
| Operating temperatre | -10 to +80 degrees | -10 to +80 degrees | -10 to +80 degrees | -10 to +80 degrees |
| Speed of material inputs | Free-fall | Free-fall | Free-fall | Free-fall |
| Filter time | 0.1 to 15 seconds, adjustable | 0.1 to 15 seconds, adjustable | 0.1 to 15 seconds, adjustable | 0.1 to 15 seconds, adjustable |
| Compressed air | 4Bar to 8Bar | 4Bar to 8Bar | 4Bar to 8Bar | 4Bar to 8Bar |
| Input caliber | Φ25mm | Φ30mm | Φ50mm | Φ80mm |
| Input quantity (based on New materials) | 150KG/Hr | 200 to 300KG/Hr | 500 to 700KG/Hr | 1000 to 1500KG/Hr |
| Metal detection precision | 0.3mm | 0.35 to 0.4mm | 0.5 to 0.6mm | 0.8 to 1.0mm |
