Top Brand Concrete Pump Truck Hb37V Hb62V Hb58V for Sale
| US$180,000.00-240,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
HB37A
Type
Concrete Pump
Shotcrete Type
Wet
Machining Process
Hydraulic
Structure
Cylinder Type
Productivity
138cbm/H
Feeding Height
-
Vibrating Amplitude
-
Certification
ISO9001: 2000, CE
Condition
New
Color
Red
Max. Speed
90km/H
Min. Turning Diameter
18.4m
Brake Distance
7m
Approach Angle
31deg
Departure Angle
12deg
Total Weight
28150kg
2ND, 3rd Axle Load
21220kg
Engine Model
6wf1
Min. Ground Clearance
285mm
Max. Engine Power
178kw
Max. Engine Torque
1862n.M
Transport Package
Nude Package
Specification
11990*2490*3900mm
Trademark
Top Brand
Origin
China
Production Capacity
50pieces/Month
Product Description
China Hot Sale Truck Mounted Concrete Pump Truck Price HB37AProducts Description
• Compact in design, 38m pump mounted on a 3-axle truck.
• Efficient pump unit, ideal for long time use.
• Agile placing boom with 5 arms with unfolding height 9.61m only, which gives a wide work range.
• One side lateral support enables to work in narrow sites.
• Controller is designed for heavy duty use, with a monitor which monitors the pump intelligently on working data management, real-time diagnostics, alarm logging, and service interval notice.
• Various configurations and high quality components.
• Damping technology boom.
• Boom stabilization control.
• Multilingual machine interface system.
• PWM+CAN dual communication mode remote control.
Specifications
| No. | Item | Unit | Parameter |
| 1 | Max. speed | km | 90 |
| 2 | Min. turning diameter | m | 18.4 |
| 3 | Brake distance | m | 7 |
| 4 | Approach angle | ° | 31 |
| 5 | Departure angle | ° | 12 |
| 6 | Chassis model | | CXZ51Q ( Japan ) |
| 7 | Total weight | kg | 28150 |
| 8 | 1st axle load | kg | 6780 |
| 9 | 2nd, 3rd axle load | kg | 21220 |
| 10 | Engine model | | 6WF1 |
| 11 | Max. Engine power | kW | 287 |
| 12 | Max. Engine torque | N.m | 1862 |
| 13 | Max. grade-ability | % | 38 |
| 14 | Fuel consumption limit | L/100km | 34 |
| 15 | Outline dimensions (Length´ Width ´Height) | mm | 11990´2490´3900 |
| Technical Data for Pumping Operation | |||
| No. | Item | Unit | Parameter |
| 1 | Theoretical output | m3/h | 138/90 |
| 2 | Max. delivery pressure | MPa | 8.7/13 |
| 3 | Reach height | m | 37.4 |
| 4 | Reach depth | m | 23.7 |
| 5 | Front outrigger transverse span | mm | 7280 |
| 6 | Rear outrigger transverse span | mm | 6600 |
Prouct Images
