Mobile Concrete Mixing Batch Plant Hzs180
| US$50,000.00-300,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
HZS180
Machining Process
Hydraulic
Structure
Rotor Type
Productivity
120m²/h
Feeding Height
1400mm
Vibrating Amplitude
1.3mm
Certification
ISO9001: 2000, CE
Condition
New
Color
White
Theoretical Productivity
180/360m3/H
Dump Height
4m
Model of Main Mixing Machine
Mao4500/3000
Mixing Power
2×55kw
Production Cycle
60s
Standard Installed Capacity
260/520kw
Batching Plant Capacity
4800L/Bin
Concrete Spiral Conveyor Capacity
110t/H
Transport Package
Nude Package
Specification
ISO9001, CE
Origin
Jiangsu Province
Production Capacity
100/Month
Product Description
? High efficiency, low fuel consumption, and environmental care.? Modular function and design; quick installation and site transfer.
? Equipped with Italy SICOMA dual-horizontal axis forced type main mixing machine, featuring superior mixing capacity and high reliability.
? Measurement, control and signal transfer element all adopt products of world famous brand; independent measuring of various kinds of materials (or cumulative measurement), stable performance and accurate measurement.
? Advanced industrial computer + PLC control mode, inferior PLC executive signal sampling and output control, superior industrial computer dynamic displays the production process and management. It can achieve full automatic control and manual control, featuring simple operation, friendly interface, high reliability and flexible expanding.
? It can also be designed according to the requirements and conditions (i.e. site, output, environmental care, structural appearance).
| Theoretical productivity | m3/h | 180/360 |
| Dump height | m | 4 |
| Model of main mixing machine | MAO4500/3000 | |
| Mixing power | kW | 2X55 |
| Nominal volume of main mixing machine | L | 3000 |
| Production cycle | s | 60 |
| Aggregate diameter | mm | ≤80 |
| Aggregate bin volume | m3 | 4X25 |
| Powder bin (optional)volume | t | 4×200 |
| Batching plant capacity | L/bin | 4800 |
| Inclined belt conveyor capacity | t/h | 900 |
| Concrete spiral conveyor capacity | t/h | 110 |
| Coal ash spiral conveyor capacity | t/h | 75 |
| Standard installed capacity | kW | 260/520 |
| Weighing range & accuracy of sand/stone | kg | (0~3600)±2% |
| Weighing range & accuracy of cement | kg | (0~1500)±1% |
| Weighing range & accuracy of coal ash | kg | (0~700)±1% |
| Weighing range & accuracy of water | kg | (0~700)±1% |
| Weighing range & accuracy of additives | kg | (0~70)±1% |
Kindly contact me:
Nicole Chen/ Sales Manager
Evangel Industrial (Shanghai) Co., Ltd.
Evangel International Machinery Ltd.
(CHINESE LEADING CONSTRCUTION MACHINERY AND SPARE PARTS EXPORTER)
Add: Suite 1326, Fortune Times Tower, No. 1438 North Shanxi Road, Shanghai, China
Web:http://evangelchina.en.made-in-china.com
