Automatic Factory Price Weighing Fiber Jacket Filing Machine with Four Weighing Units (M1-4)
| US$3,000.00-15,000.00 | 1 set (MOQ) |
Basic Info.
Model NO.
M1-4
Feature
Automatic Weighing
Filling Valve Head
Single-Head
Type
Weighing-Type Filling Machine
Warranty
1 Year
Weighing Nozzle Size
32mm, 45mm
Flow Nozzle Size
25mm
Single Error
Within 0.5g
Filling Type
Whole Piece Filling
Daily Workload
5000-9000 Times
Single Weighing Range
3-200g
Dimension
1800*1200*1900mm
Installation Size
3000*2500mm
Cycle Number
4
Accuracy
0.1g
Machine Weight
450kg
Power
4kw
Transport Package
Wooden Box
Specification
dimension: 1800*1200*1900mm
Trademark
Hexin
Origin
China
HS Code
8453800000
Production Capacity
100 Sets/Month
Product Description
One Head Four Scales Automatic Cotton Filling Machine(down also can be also filled)Product Parameters
| Model | M1-4 |
| Single Error | Within 0.5g |
| Filling nozzle size | Weighing nozzle 32mm, 45mm Flow nozzle 25mm |
| Daily workload | 5000-9000 times |
| Filling type | Whole piece filling |
| Single weighing range | 3-200g |
| Filling material | Silk cotton, ball cotton, down, wool silk |
| Dimension(mm) | 1800*1200*1900 |
| Installation Size(mm) | 3000*2500 |
| Cycle number of single head | 4 |
| Display Accuracy | 0.1g |
| Machine weight | 450kg |
| Power | 380V/4KW |
| Filling port | 1weighing nozzle+2 flow nozzle |
| Name | Brand and Origin |
| PLC | Delta/Xinje |
| Sensor | HBM(Germany) |
| Regulated power supply | MW(Taiwan) |
| Controller | Delixi |
| Pneumatic parts | AirTAC |
| Pressure Regulating Valve | Japan SMC/AirTAC |
| Touch Screen | MCGS |
Company Profile Our company is a national high-tech enterprise and has its own invention patents and multiple software works. The company has its own registered trademark and export authority, and has passed the international European Union CE certification.
Enterprise Vision: Technology Hexin Serving the World
Enterprise Spirit: Innovation for Practicality
Business philosophy: High efficiency and energy saving, create more value for customers.
FAQ Q: Are you a trading company or manufacturer ? A1: Tangshan Hexin Garment Machinery Co., Ltd. is a professional manufacturer with many years'experience.Q: What's your payment terms?
A2: We accept T/T, L/C
Q: What's the delivery time?
A3: 3~10 days. Q: Which payment period is accepted? A4:30% advance payment paid by T/T before fabrication and 70% balance payment paid by LC or TT before delivery.
