316 19*7 4.0 mm Stainless Steel Wire Rope Wire Cable Zzs

Product Description

Product Description

Product Name	Stainless Steel Wire Rope	Grade	SS304,SS316,SS316L
Diameter Range	0.8-25mm	Specifications	1x7,7x7,1x19,7x19
Surface	Galvanizing, cleaning and polishing	Customized	Support customization
Applications	It is widely used in high-speed rail connecting line, guardrail curtain wall, fishing, automobile brake line, clothes hanger and other fields.

Specification For Stainless Steel Wire Ropes
CONTURCTION COMPACTED STRAND 1x7
Product Code	Diameter (mm)	Min.Breaking Load (kn)			Weight Kg/100m
		1570/mm²	1770/mm²	1960/mm²
SS01(1x7)	1.00	0.860	0.973	1.080	0.50
SS12(1x7)	1.20	1.240	1.401	1.550	0.72
SS15(1x7)	1.50	1.940	2.190	2.420	1.13
SS18(1x7)	1.80	2.800	3.150	3.490	1.62
SS20(1x7)	2.00	3.450	3.890	4.310	2.00
SS22(1x7)	2.20	4.180	4.710	-	2.42
SS25(1x7)	2.50	5.390	6.080	-	3.13
SS30(1x7)	3.00	7.770	8.750	-	4.50
SS40(1x7)	4.00	13.800	-	-	8.34
SS50(1x7)	5.00	21.600	-	-	13.10
SS60(1x7)	6.00	31.100	-	-	18.90
CONTURCTION COMPACTED STRAND 1x19
Product Code	Diameter (mm)	Min.Breaking Load (kn)			Weight Kg/100m
		1570/mm²	1770/mm²	1960/mm²
SS01(1x19)	1.00	0.820	0.930	1.030	0.50
SS15(1x19)	1.50	1.850	2.090	2.320	1.13
SS20(1x19)	2.00	3.300	3.720	4.120	2.00
SS25(1x19)	2.50	5.150	5.810	-	3.13
SS30(1x19)	3.00	7.420	8.360	-	4.50
SS40(1x19)	4.00	13.190	-	-	8.00
SS50(1x19)	5.00	20.610	-	-	12.50
SS60(1x19)	6.00	29.700	-	-	18.00
SS80(1x19)	8.00	52.800	-	-	32.00
SS100(1x19)	10.00	82.400	-	-	50.00
SS120(1x19)	12.00	118.700	-	-	72.00
SS160(1x19)	16.00	211.000	-	-	128.00
SS200(1x19)	20.00	330.000	-	-	200.00
CONTURCTION COMPACTED STRAND 7x7
Product Code	Diameter (mm)	Min.Breaking Load (kn)			Weight Kg/100m
		1570/mm²	1770/mm²	1960/mm²
SS01(7x7)	1.00	0.520	0.590	0.650	0.36
SS15(7x7)	1.50	1.170	1.330	1.460	0.81
SS20(7x7)	2.00	2.080	2.350	2.600	1.44
SS25(7x7)	2.50	3.260	3.670	4.070	2.25
SS30(7x7)	3.00	4.690	5.290	5.860	3.24
SS40(7x7)	4.00	8.340	9.400	10.400	5.76
SS50(7x7)	5.00	13.030	14.700	16.300	9.00
SS60(7x7)	6.00	18.800	21.200	-	12.96
SS80(7x7)	8.00	33.400	37.600	-	23.04
SS100(7x7)	10.00	52.100	58.800	-	36.00
SS120(7x7)	12.00	75.100	84.600	-	51.84
SS160(7x7)	16.00	133.400	-	-	92.16
SS200(7x7)	20.00	210.000	-	-	144.00
CONTURCTION COMPACTED STRAND 7x19
Product Code	Diameter (mm)	Min.Breaking Load (kn)			Weight Kg/100m
		1570/mm²	1770/mm²	1960/mm²
SS15(7x19)	1.50	1.090	1.220	1.350	0.81
SS20(7x19)	2.00	1.920	2.170	2.400	1.44
SS25(7x19)	2.50	3.010	3.390	3.750	2.25
SS30(7x19)	3.00	4.340	4.890	5.420	3.24
SS40(7x19)	4.00	7.710	8.690	9.630	5.76
SS50(7x19)	5.00	12.050	13.580	15.040	9.00
SS60(7x19)	6.00	17.400	19.600	21.700	12.96
SS80(7x19)	8.00	30.800	34.800	38.500	23.04
SS100(7x19)	10.00	48.200	54.300	60.200	36.00
SS120(7x19)	12.00	69.400	78.200	-	51.84
SS160(7x19)	16.00	123.400	139.100	-	92.16
SS200(7x19)	20.00	193.000	-	-	144.00
SS220(7x19)	22.00	232.800	-	-	174.24
SS240(7x19)	24.00	277.000	-	-	207.36

Why Choose Us:

When the steel wire rope is cut off, each strand and each steel wire will not be scattered, and its own position and twist distance will still be maintained

Scientific and technological achievements, professional production lines and complete equipment ensure the smooth production process

Use professional testing equipment to strictly test the tensile force of products to ensure that products meet customer requirements

MORE PRODUCTS
Detailed Photos COMPANY PROFILE
CERTIFICATE With ISO9001 as the standard, the company has established a quality system and operated effectively. Stainless steel wire rope products are widely used in operation, railway, bridge, construction, decoration, high lift tower crane, crane, conveyor belt, aviation and other important places. Enterprises with its quality products, to the international market. Packing & Delivery Normal packaging: wooden shaft or plastic shaft shall be used and placed on the tray. If the customer has customized packaging requirements, it can be packaged according to the customer's requirements

Trade terms	FOB, EXW, CIF, DDU, DDP
Payment terms	T/T, L/C, Negotiable
MOQ	1000m
Supply capability	100000 pieces per month
Lead time	15-30 days
Shipment	Express, air, sea
Port	Shanghai, Ningbo, Shenzhen
Sample availability	Yes
Sample time	3-7 days
Packaging	Plastic shaft or wooden shaft & Pallet

Company Profile
Taizhou Qiangda Stainless Steel Wire Rope Co., Ltd. is located in Dainan, a famous "Stainless Steel Town" in China. Our company was founded in August 2004, formerly known as Xinghua Qiangda Steel Wire Rope Factory. We mainly produces Stainless steel wire rope, Stainless steel wire, Galvanized steel wire rope, Plastic coated steel wire rope, Invisible protective net wire rope, Car and motorcycle wire rope, High-speed professional wire rope, Bridge special steel wire rope and wire rope sling. With advanced production technology, strong technical force and complete testing equipment, it has an annual production capacity of 4, 000 tons of various steel wire ropes and an annual output of 1, 000 tons of stainless steel wire. The product quality ranks among the best in the industry. With the quality policy of "Creating with Scientific Management, Developing by Innovation, Quality Service for Customers". Our company pays close attention to the needs of domestic and foreign markets, and continuously introduces various varieties of multi-species, special wire ropes and steel wires. Production in strict accordance with GB, ISO, DIN, JIS, BS and other standards. Our products are widely used in handling, high-speed rail, bridges, architectural decoration, high lift tower cranes, cranes, conveyor belts, aviation and other important places. The wire rope production diameter is 0.5-46mm, which wins the trust of domestic and foreign customers with satisfactory price and excellent service. The company has successively obtained "ISO9001 Quality System Certification", "National Industrial Product License", "SGS Certification", "Jiangsu Private Technology Enterprise", "Jiangsu High-tech Enterprise", "International Standard Product Mark Certificate", "AAA Level Standardized Good Behavior Certificate", etc. Our company, with high-quality products, enter the international market. Our products are very popular in Europe and the United States, the Middle East, Southeast Asia and other countries and regions. We whole-heartedly welcome domestic and foreign customers to visit and negotiate business.
