16L Ultra Low Spraying Volume Nozzle Farm Sprayer Drone

Product Description

16kg agriculture pesticide sprayer drone for sale
- OEM & ODM Service -

Product Description

Remote control eye escort
D16L-4 supports digital image transmission technology, and the remote control range can reach 3,000 meters.Equipped with wide-angle FPV camera and night searchlight, it can monitor the aircraft operating environment to ensure operation safety.
Product Specifications
BROUAV adopts industrial grade hardware structure and sensors, available for more communication modes.

Model	D16L-4
Product Material	Aviation carbon fiber + aviation aluminum
Airframe Dimensions(Incl. propellers)	1870*1870*635mm
Airframe Dimensions(folded)	730*730*635mm
Transport Dimensions	900*780*650mm
Max Takeoff Weight	36KG
Aircraft Weight	16KG Excluding Battery
Maximum Capacity(spraying system)	16L
Flight Altitude	≤30 meters
Flight Time (Unloaded)	10~20 minutes
Flight Time (Full Loaded)	6~10 minutes
Flight Speed	1-10 m / sec
Spray Width	4-8 meters
Spray Flow	2-5L/min double pump adjustable
Nozzle Type	Imported high pressure anti-floating atomizing nozzle
Droplet Size	60~500μm
Flight Controller	Industrial Version GPS and Controller
Navigation Method	GPS/GNSS RTK
Operating Efficiency	≥8(ha/hr)
Safe Takeoff and Landing Wind Speed	≤8 m/s
Motor speed	5000rpm
Battery Voltage	60.9V
Battery Capacity	20000mAh*1( 14S Intelligent Lithum Battery)

Features
1. The fuselage adopts a closed design, which can prevent pesticides from entering the flight control system and provide safety guarantee for long-term operation;2. The plant protection machine has built-in GPS and compass module, with fixed-height and fixed-point flight function, which can well maintain the spray height and spray route accuracy of the operation;3. The height limit and flight speed limit of spraying operation can be set. The high-pressure spraying system has good atomization effect. Under the wind pressure of the aircraft, the drug mist has the characteristics of strong penetration. Leaf face.4. Modular design of functional components, easy maintenance and upgrade.5. Using intelligent plug-in battery6. Use quick-plug medicine barrel7. High-pressure brushless water pump is adopted, and the ESC is fully waterproof.8. Wear the case, optimize the whole machine, and hide the medicine circuit.9. 7075 aviation aluminum (high grade) is used for the folding part.10. Alternating spraying function, the spray head can be switched independently.11. The arm can be quickly disassembled.
Don't puncture the battery. If the battery pack is drummed, there is a safety hazard. Especially when charging, the drum pack should be stopped immediately and the battery should be moved to a safe place.
