Rock Salt Fine Powder Pin Mill 100 Mesh White Powdered Sugar Grinding Mill Machine

Product Description

Product Description

Rock salt fine powder pin mill 100 mesh white powdered sugar grinding mill machine
Product Application BSG sugar powder mill machine can be widely used in different fields of chemical industry, foodstuff
industry... The auxiliary machine includes a cyclone dust collector and a bag filter, which can collect air more tightly; the main machine is equipped with an active crushing disc device, and the direction of the hammer head can be changed. In addition to crushing, BSG powdered sugar mill machine also has the functions of grading and winnowing centrifugal shearing, which can control the particle size. After the material is crushed, it is sent to the air outlet by negative pressure.

Working method:

Raw material enters into the grinding chamber through the feed hopper, impacted by the high speed rotary cutter, thrown to the fixed liner, then is bounced and sheared. Beside the grinding chamber there is a high speed fan blade, which produces positive pressure air flow. Under the force the pressure air, powder goes through the screen more quickly and be absorbed into the cyclone. Part of the superfine powder goes to the pulse dust collecting box, so there is no waste and no fly dust during production.

TECHICAL PARAMETER FOR BSG-sugar powder grinder machine
Model	BSG-300	BSG-400	BSG-500	BSG-600	BSG-700
Speed of main shaftrpm	5300	4800	3800	3300	2800
Main motor (KW)	5.5	7.5	15	22	30
Blower(KW)	2.2	2.2	7.5	15	18
Discharge motor(KW)	0.37	0.75	0.75	0.75	1.1
Grinding fineness (mesh)	10-120	10-120	10-120	10-120	10-120
Capacity kg/h	50-500	100-1000	300-1500	500-2500	1000-5000

Main Features 1) Simple structure ,easy in installation and maintenance.
2) Adopting advanced world famous brand motor ,electric parts,bearing and operation parts.
3) No dust during production, and dust can be collected in dust collecting box.
4) During production,temperature remains normal, will not get hot. So material's color and nature won't change.
5) Uniqe design, with same power consumption, it can achieve much bigger capacity
Detailed Images
Crusher part
Unique design,crusher part won't get hot even though working for hours.
Color and nature of material won't change.
Change powder size by changing different mesh screen.
Cyclone part

(1) Cyclone can separate dust from powder(granules)
(2) Rotary valve make powder discharge speed even
Rotary valve is also made of stainless steel
and to clean it and dismantle is convenient.

Pulse Dust Collecting box
(1) Dust is collected inside the dust collecting box.
(2} Inside box, there are many dust collecting bags and the bag frames are also made of stainless steel and can be disassembled easily.
(3) With pulse-jet cleaning, dust can be collected very conviniently.

TO MAKE SURE BETTER QUALITY

1) We use motor from ABB/Siemens/WEG
2) We adopts electrical control parts from Delixi
3) We use bearings from
BSU universal crusher
Remark: The crusher part of our BSU universal crusher is the same as BSG's,if your budget is a little limited,you can choose this single machine. And 2,500 USD is just the price of the smallest model- BSU-20.If you want to know the price and details for bigger models,please kindly send me an inquiry.
Company Information
Our company-Brightsaill Machinery Co., Ltd is focus on the research of powder equipment, such as powder making machine, sugar powder grinder machine, herb powder making machine... etc. Our products can be applied in food, chemical and other industries and had won a good reputation.
After 15 year's development and accumulation, our company has been one of the most influential equipment manufacturers in the industry. And we wish to grow up and develop together with all new and old customers.
Our Service
Pre-Sales Service
* Inquiry and consulting support with 24 hours
* Sample testing support.
* View our Factory.
After-Sales Service
* Instructing how to install the machine, insutructing how to use the machine.
* Engineers available to service machinery overseas.
Packing & Delivery
