High Performance Cheap Price Textile Machine Top Sale Coil Ceramic Wire Guide Roller

Product Description

High Performance Cheap Price Textile Machine Top Sale Coil Ceramic Wire Guide Roller
Product Description:
1. In the wire and cable industry, ceramics has become the material of choice and convenience. Almost all facets of wire and cable manufacture have benefited by the use of ceramics in the production processes.
2. Product quality and output have been maximized with minimum downtime; Lower wear
Problems and surface defects.
3. Pulley flanges, CNC Machined and available in fully anodized Aluminum, coated with anti corrosion layers, are not affected by most wire drawing solutions and do not need frequent maintenance vis-à -vis Phenolic materials. The flanges are held together by means of SS screws. High performance bearings are used and are pressed fitted into the metal flanges. The metal part is duly anodized to prevent rusting.
Product Feature:
1. Flanged ceramic roller, Wire guide pulleys (ceramic pulleys) is commonly used component when wire passing is required, it can be used in coil winding machine, cable machine and the textile machinery as well. The porcelain ring is mounted on the bearing, Coil winding wire guide pulley(wire roller) will rotate by the thread and wire passing on the surface of the ring. Thus the sliding friction has been converted to the static friction.
2. But at the start and stop, in order to overcome the inertia, there will be a partial sliding friction. The surface Polish degree of the porcelain ring reaches Ra0.2; The beating during rotation is under 0.15. We select the 99% AL2O3 as the material with the hardness of HRA88 and the density of 3.85...Two nylon side walls have been put to the both side of the ceramic ring and the bearing, coil winding wire guide pulley (wire roller) combines one wire roller.
Service:
1. With many available designs and configurations, such as bolt together, solid ceramic, or coated aluminum. HARTAI can satisfy the unique requirements of the wire and cable industry.
2. HARTAI's AL95 guide pulleys are long lasting, will help improve wire surface quality and at the same time reduce maintenance and production costs.
3. HARTAI offers dozens standard sizes of guide pulleys. A large inventory of pulleys is maintained for the most widely used sizes for immediate delivery. Guide pulleys can also be manufactured to specific requirements and detail.
Features :
1.The middle ceramic coil is made of precise ceramic and matched with high-speed bearing 2. The winding tension can be maintained in a stable manner through the pulleys .
3.Baffles in both sides can prevent the wire to jump out of the groove .
4.The groove is polished to Ra0.2 .
Advantages :
1.Easy to be installed
2.Low coefficient of frictio
3. High speed running bearing
4.High quality and competitive prices

Specifications of ceramic wire guide small pulley

Modle No.	A(mm)	B(mm)	C(mm)	D(mm)
HT001	7.8	6	2	3.2
HT002	8	8	2	4
HT003	10.6	7.3	2	3.5
HT004	12	10	4	4
HT005	14	10	3	6
HT005-C04	21.5	14	4	10
HT005-C05	21.5	14	5	10
HT006-C05	30	24	5	11
HT006-C06	30	24	6	11
HT006-C07	30	24	7	11
HT006-C08	30	24	8	11
HT007-C05	35	24	5	11
HT007-C06	35	24	6	11
HT007-C07	35	24	7	11
HT007-C08	35	24	8	11
HT008-C05	40	24	5	12
HT008-C06	40	24	6	12
HT008-C07	40	24	7	12
HT008-C08	40	24	8	12
HT009-C09	45	36	9	13.5
HT009-C10	45	36	10	13.5

Display of the ceramic wire guide small pulley

Information of our company
HARTAI Technology Industry Co., Ltd , found in 2001, is located in the beautiful city of China's manufacturing industry Dongguan City. It is committed to nozzle, ruby products, tungsten carbide products, ceramic products, plastic crochet hook and precision machinery manufacturing .Our main products are nozzle, ceramic roller, jump wire preventer, various sizes of ceramic eyes, combination wire roller, ceramic wheel and non-standard parts, all kinds of tension and so on.
FAQ
1. How can I get a quotation?

You can find our contact information below this page and some detail information will be very helpful to get an exact quotation. We will give quotation within 24hours, if urgent, please tell us and we will regard your inquiry priority.

2. How can I get a sample?

As the price confirmed, you can require for samples.

3. Can you do the design for us?

Yes, we have our factory and we can make OEM order.


4. How long can I expect to get the sample?

Normally it takes 7-15days to produce the sample.


5. What about the lead time for mass production?

It depends on what kind of products you ordered. Generally, 15-25days for mass order.
