Module spare parts SCXI-1102

Product Details

Product Description

Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

SCXI-1102

X10 Auxiliary voltage for power supply 3 pin Weidmueller female BLAT3BSNOR + fixing set SLABB2RORSET X20 Binary Inputs of the 1st BIO Harting 09 06 000 9474, DIN 41612 X21 Binary outputs of the 1st BIO Harting 09 06 000 9474, DIN 41612 X30 Binary Inputs of the 2nd BIO Harting 09 06 000 9474, DIN 41612 X31 Binary outputs of the 2nd BIO Harting 09 06 000 9474, DIN 41612 X40 Binary Inputs of the 3rd BIO Harting 09 06 000 9474, DIN 41612 X41 Binary outputs of the 3rd BIO Harting 09 06 000 9474, DIN 41612 X50 Analog output Harting 09 06 000 9474, DIN 41612 X70 Ethernet interface (full version) Not available yet X71 CAN interface (full version) Not available yet X72 RS232 interface 9 pin D-sub connector male X73 RS485 interface 9 pin D-sub connector male X74 IRIG-B interface (full version) Not available yet X75 Fast I/O inputs (full version) Not available yet X76 Fast I/O outputs (full version) Not available yet X77 Fast I/O inputs (full version) Not available yet X80 Analog inputs (from CT and/or VT) Connector kit Compel c/w 24 contacts - Short version code 350.040.902 - Long version code 350.040.903 Crimp any single contact with hand tool No 350.048.011 X81..88 Analog input (sensor channel 1..8) BNC Twin Cam CPE 23.717.140-0333 Table 3: Connectors on Central Unit for SPABUS connection, electrical RS232 (modified) Connector Descriptions Type of connector plug X60 RS232 (modified) 9 pin D-sub connector male (z-modem) Note The RS232 connector, modified and galvanic isolated, can be applied to connect to a LON/SPA gateway. Table 4: Connectors on Central Unit for SPABUS connection, plastic fiber optical cable Connector Descriptions Type of connector plug X60 TX (optical interface) Snap in HP HFBR 4501 (gray) X61 RX (optical interface) Snap in HP HFBR 4511 (blue) Caution The cable length for SPABUS connection with plastic fiber optical cable should not exceed 30 m REF 542plus switchbay protection and control unit Manual Part 3: Installation and Commissioning 1VTA100004-en DMS,2001-10-04 REF542plus: Installation and Commissioning 19 / 80 Table 5: Connectors on Central Unit for SPABUS connection, glass fiber optical cable Connector Descriptions Type of connector plug X60 TX (optical interface) ST plug HITRONIC ST-125 X61 RX (optical interface) ST plug HITRONIC ST-125 Caution The cable length for SPABUS connection with glass fiber optical cable should not exceed 1000 m Table 6: Connectors on Central Unit for LON per LAG 1.4 respectively IEC 60870-5-103 Connector Descriptions Type of connector plug X60 TX (optical interface) ST plug HITRONIC ST-125 X61 RX (optical interface) ST plug HITRONIC ST-125
