Construction Equipment Used Hydraulic Truck Mounted Mixer for Sale

Product Description

Product Description
No. Item Unit Parameter

1	Max. speed	km	90
2	Min. turning diameter	m	18.4
3	Brake distance	m	7
4	Approach angle	°	31
5	Departure angle	°	12
6	Chassis model		CXZ51Q ( Japan )
7	Total weight	kg	28150
8	1st axle load	kg	6780
9	2nd, 3rd axle load	kg	21220
10	Engine model		6WF1
11	Max. Engine power	kW	287
12	Max. Engine torque	N.m	1862
13	Max. grade-ability	%	38
14	Fuel consumption limit	L/100km	34
15	Outline dimensions (Length´ Width ´Height)	mm	11990´2490´3900

Technical Data for Pumping Operation


No. Item Unit Parameter

1	Theoretical output	m3/h	138/90
2	Max. delivery pressure	MPa	8.7/13
3	Reach height	m	37.4
4	Reach depth	m	23.7
5	Front outrigger transverse span	mm	7280
6	Rear outrigger transverse span	mm	6600
7	Outrigger longitudinal span	mm	6860
8	Delivery pipe diameter	mm	125
9	Remote control distance	m	100
10	Placing boom slewing range	°	370

Company Profile
FAQ
1:What are your main export construction machineries?
A:Used concrete mixer truck,Used trailer concrete pump,Used concrete line pump,Used Truck mounted concrete pump,Concrete batching plant,used cranes,used excavators,used road machinery, used piling machinery and so on.Ranging second-hand original machineries to refurbished machineries .
2:Is your company a factory or a trader?
A:We are re-manufacturing factory with a big used construction machinery trading platform.we specialize in construction machinery wholesale and concrete machinery re-manufacturing for more than 13 years.
3:What are the advantages of re-manufacturing machineries and what quality of your refurbished machineries?
A:The big advantage is price of used machine,value of new machine.We set the highest maintenance and re-manufacturing standard system,strictly inspect and repair according to the standard,Our each re-manufacturing will go through 14 processes from admission test to final inspection to make sure the best quality.
4:How do I know the condition of the original used or re-manufacturing concrete pump truck?
A: We will provide a video of the specifications and the test of the pump truck before we ship to you.
5:What is the minimum order quantity for your used machinery?
A: The MOQ is 1 unit.
