10 Ports Poe Switch 8*10/100Mbps Poe Ports, 2*10/100Mbps up-Link Port Comply with IEEE802.3af/at Pd Equipment

Product Description

10 ports PoE switch 8*10/100Mbps PoE Ports, 2*10/100Mbps Up-Link Port comply with IEEE802.3af/at PD equipment Product Description SP-0802FEB is an faster 10 ports PoE switch with up-link ports designed with desktop metal case, easy to provide power and data for IP camera, IP phone...
All 10 ports support auto-negotiation, auto MDI/MDIX and standard IEEE 802.3af/at POE, simply plug and play. With the innovative energy-efficient technology, users can choose the PoE switch according power consumption, making it an eco-friendly solution for home/business networking.
Main Features:
1. Desktop metal case, easy to set up.
2. 8*10/100Mbps PoE Ports, 2*10/100Mbps Up-Link Port
3. 8 PoE ports, comply with IEEE802.3af/at PD equipment
4. Support PoE power up to 30W for IEEE802.3at PD equipment, up to 15W for IEEE 802.3af PD equipment
5. Port priority: if all PoE PD equipment power consumption become overloaded, a priority will be arranged among the PoE ports, then the system will cut off the power of the lowest-priority port.
6. With VLAN button, support port isolation.

Model	SP-0802FEB
CPU	IP175G+IP178G+IP808AR
Standard	IEEE802.3 10BASE-T Ethernet IEEE802.3u 100BASE-TX faster Ethernet ANSI/IEEE 802.3 NWay Auto-Negotiation IEEE802.3 af IEEE802.3at
Ports	8 * 10/100M auto Negotiation /auto MDI/MDIX PoE Ports
	2 * 10/100M auto Negotiation /auto MDI/MDIX up-link Port
	1 * VLAN switch
Cable requirement	10BASE-T: UTP 3, 4, 5 cable (≤100 meters)
	100BASE-TX: UTP 5 cable (≤100 meters)
IEEE802.3 af	Support/15.4W
IEEE802.3at	Support/30W
POE	SP-0802FEB: 96W, AC 100 V~240 V 50/60 HZ up to 30W for PoE port
	Optional: SP-0802FEB: 120W, AC 100 V~240 V 50/60 HZ up to 30W for PoE port
Overload Protection	SP-0802FEB: 92W
	SP-0802FEB: 120W
PoE Standard	IEEE 802.3, 802.3u, 802.3x, 802.3af,802.3at
Advanced Functions	Comply with IEEE 802.3at/af PDs
	Port Priority Function
	Support storage forwarding
	MAC Address Auto-Learning and Auto-Aging.
	IEEE802.3X Flow Control for Full-Duplex Mode and Backpressure for Half-Duplex Mode
	Optional: 10BASE-T: UTP 5 cable (≤250 meters)
Backplane Bandwidth	Non data limiting, recommend to work with IP camera
MAC Address Table	2K
Forwarding Rate	10BASE-T:14800pps/port
	100BASE-TX:148000pps/port
LED Indicator	PWR LINK for each port
Size(L*W*H)	210mm*136mm*44.5mm
Working Environment	Working Temperature: 0ºC~40ºC
	Storage Temperature: -40ºC~70ºC
	Working Humidity: 10%~90% No Condensation
	Storage Humidity: 5%~90% No Condensation
